SURFACE MOUNT-125 C
UPGRADE
MVH
Series
Surface Mount
Vertical Chip
High
Temperature
Solvent Proof
(10-50V )
125 C
Maximum
Temperature
Engineering Bulletin Jul 03
MVH
Actual
Size
The MVH series capacitors are surface mount, high temperature vertical chip capacitors designed for
reflow soldering. This series has been expanded to cover a wider variety of CV and case sizes. The
MVH capacitors have a maximum operating temperature of 125 C, which makes them ideal for use
in automotive and other high temperature applications.
The MVH series capacitors
except for those rated at 63-450 volts
are solvent proof. Refer to the
Mini-Glossary for cleaning guidelines and recommended cleaning agents that are compatible with
United Chemi-Con products.
Summary of Specifications
Surface mount lead terminals.
Capacitance range: 3.3 to 4,700µF.
Voltage range: 10 to 450VDC.
Category temperature range: 40 C to 125 C.
Leakage current: See specifications table for leakage current values at 20 C.
Standard capacitance tolerance: 20%
Nominal case size (D L): 6.3 5.7mm to 18 21.5mm.
Rated lifetime: 1,000 to 5,000 hours at 125 C depending on case size and voltage.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
1/ 5
SURFACE MOUNT-125 C
MVH Series
MVH Specifications
Item
Category Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
40 to 125 C
10 to 450VDC
3.3 to 4,700 F
20% ( M ) at
10 -100V: I
160 - 450V: I
20 C, 120Hz
Characteristics
Engineering Bulletin Jul 03
MVH
0.03CV or 4 A, whichever is greater, after 2 minutes at
0.04CV 100 A after 2 minutes at 20 C.
20 C.
Where I = Max. leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( V )
Dissipation Factor ( Tan )
At
20 C, 120Hz
10
0.24
0.22
16
0.20
0.18
25
0.16
0.16
35
0.14
0.14
50
0.14
0.12
63
0.18
0.14
100
0.18
0.10
160-250
–
0.20
400-450
–
0.24
Rated Voltage ( V )
Case F60 - J10
Case K14 - M22
When nominal capacitance exceeds 1,000 F, add 0.02 to the values above for each 1,000 F increase.
Low Temperature
Characteristics
At 120Hz, impedance ( Z ) ratio between the
exceed the values given below.
Rated Voltage ( V )
Z ( 25 C ) / Z ( 20 C )
F60 - J10
K14 - M22
F60 - J10
K14 - M22
10
4
4
10
8
16
3
3
8
6
25 C or
25
2
2
6
4
35
2
2
4
3
40 C value and
50
2
2
4
3
63
2
2
4
3
100
2
2
4
3
20 C value shall not
160-250
–
3
–
6
400-450
–
6
–
10
Z ( 40 C ) / Z ( 20 C )
Endurance
(Load Life)
The following specifications shall be satisfied when the capacitors are restored to
subjecting them to the DC rated voltage for the specified test time at 125 C.
Case Code
Rated Voltage
Test Time
F60 - H63
10 -100V
1,000 Hours
H10 & J10
10 -100V
2,000 Hours
K14 - M22
10 -100V
5,000 Hours
20 C after
K14 - M22
160 - 450V
2,000 Hours
Capacitance change :
≤
30% of the initial measured value
Tan ( DF )
:
≤
300% of the initial specified value
Leakage current
:
≤
initial specified value
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20 C after
exposing them for the specified test time at 125 C without voltage applied. The rated voltage
shall be applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more
than 48 hours before the measurements.
Case Code
Rated Voltage
Test Time
10 - 250V
1,000 Hours
F60 - M22
400 - 450V
500 Hours
Capacitance change:
≤
30% of the initial measured value
Tan ( DF )
:
≤
300% of the initial specified value
Leakage current
:
≤
initial specified value for 10 - 50V
:
≤
500% of the initial specified value for 63 - 450V
2/5
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
SURFACE MOUNT-125 C
MVH Series
Diagram of Dimensions
Vertical Chip SMD Lead Terminals
VC Type
Ø
D =
Ø
6.3 -
Ø
12.5
*
MARKING STYLE A
Capacitance
Engineering Bulletin Jul 03
MVH
Unit: mm
VD Type
Ø
D =
Ø
16 &
Ø
18
MARKING STYLE B
Capacitance
Recommended PCB Land Patterns
VC Type
Ø
D =
Ø
6.3 -
Ø
12.5
V
Rated Voltage
D
D
V
c
Rated Voltage
Location of
Capacitor
a
b
Solder Land
L
L
VD Type
Ø
D =
Ø
16 &
Ø
18
0.3 MAX.
B
0.3 MAX.
a
B
Dummy
Terminals (2)
b
c
f
e
A
W
A
W
d
Location of
Capacitor
Solder Land
P
C
P
C
*
Marking Style B is used for all
Ø
12.5 VC Type products.
Refer to Packaging section for Surface Mount taping,
reel and tray specifications and Surface Mount Soldering
section for reflow soldering conditions.
Case and PCB Land Pattern Dimensions
Case
Code
F60
F80
H63
H10
J10
K14
K16
L17
L 22
M17
M22
Ø
D
0.5
Ø
6.3
Ø
6.3
Ø
8
Ø
8
Ø
10
Ø
12.5
Ø
12.5
Ø
16
Ø
16
Ø
18
Ø
18
L
5.7
7.7
6.3
10.0
10.0
13.5
16.0
16.5
21.5
16.5
21.5
0.3
0.3
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
A
0.2
6.6
6.6
8.3
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
B
0.2
6.6
6.6
8.3
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
C
0.2
7.2
7.2
9.0
9.0
11.0
13.7
13.7
18.0
18.0
20.0
20.0
W
0.5-0.8
0.5-0.8
0.5-0.8
0.7-1.1
0.7-1.1
1.0-1.3
1.0-1.3
1.0-1.3
1.0-1.3
1.0-1.3
1.0-1.3
P
1.9
1.9
2.3
3.1
4.5
4.2
4.2
6.5
6.5
6.5
6.5
a
1.9
1.9
2.3
3.1
4.5
4.0
4.0
6.0
6.0
6.0
6.0
b
3.5
3.5
4.5
4.2
4.4
5.7
5.7
6.9
6.9
7.9
7.9
c
1.6
1.6
1.6
2.2
2.2
2.5
2.5
2.5
2.5
2.5
2.5
d
–
–
–
–
–
–
–
6.5
6.5
6.5
6.5
e
–
–
–
–
–
–
–
11.0
11.0
13.0
13.0
f
–
–
–
–
–
–
–
19.2
19.2
21.2
21.2
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
3/5
SURFACE MOUNT-125 C
MVH Series
Part Numbering System for MVH Series
MVH
10
VC
221
M
H10
TP
Engineering Bulletin Jul 03
When ordering, always specify complete catalog number for MVH Series.
MVH
Packaging: TP = Standard Taping for D55 - K16.
TR = Plastic Tray for L17- M22; Optional for K14 - K16.
Case Code: See Case Sizes in Tables.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in Microfarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
for capacitance of 100 F or more. R indicates the decimal point for
capacitance less than 100 F (e.g. R22 = .22 F; 2R2 = 2.2 F;
22R = 22 F; 221 = 220 F; 222 = 2,200 F; 223 = 22,000 F ).
Lead Configuration: VC = Vertical Chip, 2 SMD Terminals.
VD = Vertical Chip, 4 SMD Terminals (2 dummy).
DC Rated Voltage: Expressed in Volts (e.g.10 = 10WVDC).
Series Name: Indicates Basic Capacitor Design.
Standard Voltage Ratings - Surface Mount (10 -100V )
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Case
Code
Maximum ESR
(
Ω
) at
20 C, 100kHz
F80
H63
H10
J10
K14
L17
M17
M17
M22
F60
K14
K14
L17
M17
M17
F60
F80
H63
H10
J10
K14
K14
L17
L17
M17
M22
F60
F60
F80
H63
H10
J10
K14
L17
K16
L17
M17
2.3
2.3
1.0
0.7
0.14
0.10
0.10
0.10
0.058
3.3
0.14
0.14
0.10
0.10
0.10
3.3
2.3
2.3
1.0
0.7
0.14
0.14
0.10
0.10
0.10
0.058
3.3
3.3
2.3
2.3
1.0
0.7
0.14
0.10
0.11
0.10
0.10
40 C, 100kHz
46
46
20
13.4
2.1
1.5
1.5
1.5
0.87
66
2.1
2.1
1.5
1.5
1.5
66
46
46
20
13.4
2.1
2.1
1.5
1.5
1.5
0.87
66
66
46
46
20
13.4
2.1
1.5
1.5
1.5
1.5
Rated
Ripple Current
( mA rms) at
125 C, 100kHz
72
72
136
188
750
1,000
1,200
1,200
1,550
43
750
750
1,000
1,200
1,200
45
68
68
126
211
750
750
1,000
1,000
1,200
1,550
27
39
62
62
92
151
750
1,000
900
1,000
1,200
10 Volts
13 Volts Surge
100
100
220
330
1,000
2,200
2,200
3,300
4,700
47
470
680
680
1,000
2,200
33
47
47
100
220
330
470
470
680
680
1,000
10
22
33
33
47
100
330
330
470
470
680
MVH10VC101MF80TP
MVH10VC101MH63TP
MVH10VC221MH10TP
MVH10VC331MJ10TP
MVH10VC102MK14TP
MVH10VD222ML17TR
MVH10VD222MM17TR
MVH10VD332MM17TR
MVH10VD472MM22TR
MVH16VC47RMF60TP
MVH16VC471MK14TP
MVH16VC681MK14TP
MVH16VD681ML17TR
MVH16VD102MM17TR
MVH16VD222MM17TR
MVH25VC33RMF60TP
MVH25VC47RMF80TP
MVH25VC47RMH63TP
MVH25VC101MH10TP
MVH25VC221MJ10TP
MVH25VC331MK14TP
MVH25VC471MK14TP
MVH25VD471ML17TR
MVH25VD681ML17TR
MVH25VD681MM17TR
MVH25VD102MM22TR
MVH35VC10RMF60TP
MVH35VC22RMF60TP
MVH35VC33RMF80TP
MVH35VC33RMH63TP
MVH35VC47RMH10TP
MVH35VC101MJ10TP
MVH35VC331MK14TP
MVH35VD331ML17TR
MVH35VC471MK16TP
MVH35VD471ML17TR
MVH35VD681MM17TR
6.3
8
8
10
12.5
16
18
18
18
6.3
12.5
12.5
16
18
18
6.3
6.3
8
8
10
12.5
12.5
16
16
18
18
6.3
6.3
6.3
8
8
10
12.5
16
12.5
16
18
7.7
6.3
10
10
13.5
16.5
16.5
16.5
21.5
5.7
13.5
13.5
16.5
16.5
16.5
5.7
7.7
6.3
10
10
13.5
13.5
16.5
16.5
16.5
21.5
5.7
5.7
7.7
6.3
10
10
13.5
16.5
16
16.5
16.5
16 Volts
20 Volts Surge
25 Volts
32 Volts Surge
35 Volts
44 Volts Surge
*
Refer to diagrams for detailed case size dimensions.
4/5
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
SURFACE MOUNT-125 C
MVH Series
Standard Voltage Ratings - Surface Mount (10 -100V )
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Case
Code
Engineering Bulletin Jul 03
MVH
Maximum ESR
(
Ω
) at
20 C, 100kHz
40 C, 100kHz
66
46
46
20
13.4
3.5
3.5
2.3
2.7
2.3
2.3
115
115
50
35
12.5
10
9
5.5
50
35
16.5
13
12
8
Rated
Ripple Current
( mA rms) at
125 C, 100kHz
38
50
50
83
111
550
550
850
700
850
920
42
42
56
71
500
600
820
1,100
53
63
450
550
650
950
50 Volts
63 Volts Surge
10
22
22
33
47
100
220
220
330
330
470
10
10
22
33
100
220
330
470
10
22
47
68
100
220
MVH50VC10RMF60TP
MVH50VC22RMF80TP
MVH50VC22RMH63TP
MVH50VC33RMH10TP
MVH50VC47RMJ10TP
MVH50VC101MK14TP
MVH50VC221MK14TP
MVH50VD221ML17TR
MVH50VC331MK16TP
MVH50VD331ML17TR
MVH50VD471MM17TR
MVH63VC10RMF80TP
MVH63VC10RMH63TP
MVH63VC22RMH10TP
MVH63VC33RMJ10TP
MVH63VC101MK14TP
MVH63VC221MK16TP
MVH63VD331ML17TR
MVH63VD471ML22TR
MVH100VC10RMH10TP
MVH100VC22RMJ10TP
MVH100VC47RMK14TP
MVH100VC68RMK16TP
MVH100VD101ML17TR
MVH100VD221MM22TR
6.3
6.3
8
8
10
12.5
12.5
16
12.5
16
18
6.3
8
8
10
12.5
12.5
16
16
8
10
12.5
12.5
16
18
5.7
7.7
6.3
10
10
13.5
13.5
16.5
16
16.5
16.5
7.7
6.3
10
10
13.5
16
16.5
21.5
10
10
13.5
16
16.5
21.5
F60
F80
H63
H10
J10
K14
K14
L17
K16
L17
M17
F80
H63
H10
J10
K14
K16
L17
L22
H10
J10
K14
K16
L17
M22
3.3
2.3
2.3
1.0
0.7
0.23
0.23
0.15
0.18
0.15
0.15
2.3
2.3
1.0
0.7
0.25
0.2
0.18
0.11
1.0
0.7
0.33
0.26
0.24
0.16
63 Volts
79 Volts Surge
Not Solvent Proof
100 Volts
125 Volts Surge
Not Solvent Proof
Standard Voltage Ratings - Surface Mount (160 - 450V )
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Case
Code
Maximum ESR
(
Ω
) at
20 C, 120Hz
Rated
Ripple Current
( mA rms) at
125 C, 120Hz
100
180
245
380
100
180
250
245
315
110
205
200
260
70
100
140
135
65
85
145
160 Volts
200 Volts Surge
Not Solvent Proof
10
22
33
68
10
22
33
33
47
10
22
22
33
4.7
6.8
10
10
3.3
4.7
10
MVH160VC10RMK14TP
MVH160VD22RML17TR
MVH160VD33RMM17TR
MVH160VD68RMM22TR
MVH200VC10RMK14TP
MVH200VD22RML17TR
MVH200VD33RML22TR
MVH200VD33RMM17TR
MVH200VD47RMM22TR
MVH250VC10RMK16TP
MVH250VD22RML22TR
MVH250VD22RMM17TR
MVH250VD33RMM22TR
MVH400VC4R7MK14TP
MVH400VD6R8ML17TR
MVH400VD10RML22TR
MVH400VD10RMM17TR
MVH450VC3R3MK16TP
MVH450VD4R7ML17TR
MVH450VD10RMM22TR
12.5
16
18
18
12.5
16
16
18
18
12.5
16
18
18
12.5
16
16
18
12.5
16
18
13.5
16.5
16.5
21.5
13.5
16.5
21.5
16.5
21.5
16
21.5
16.5
21.5
13.5
16.5
21.5
16.5
16
16.5
21.5
K14
L17
M17
M22
K14
L17
L22
M17
M22
K16
L22
M17
M22
K14
L17
L22
M17
K16
L17
M22
33.16
15.07
10.05
4.88
33.16
15.07
10.05
10.05
7.05
33.16
15.07
15.07
10.05
84.66
58.51
39.79
39.79
120.57
84.66
39.79
200 Volts
250 Volts Surge
Not Solvent Proof
250 Volts
300 Volts Surge
Not Solvent Proof
400 Volts
450 Volts Surge
Not Solvent Proof
450 Volts
500 Volts Surge
Not Solvent Proof
*
Refer to diagrams for detailed case size dimensions.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
5/5
京公网安备 11010802033920号
EEWORLD
