Datasheet
•
Current rating 10 and 25 Amps
•
Output voltage 24-280 VAC
•
Triac Output (Resistive Loads Only)
•
Available with or without IP20 touch-safe cover
•
LED Input Status Indicator
•
UL Approved, CE Compliant to EN60950-1
•
Improved SEMS screw and washer
•
Screw or Quick Connect
•
Redesigned housing with anti-rotation barriers
•
EMC Compliant to level 3
For Generation 3 datasheet
click here
Panel Mount
GNA5 Series
PRODUCT SELECTION
Control Voltage
3-32 VDC
90-280 VAC
10 A
84134900
84134901
25 A
84134910
84134911
AVAILABLE OPTIONS
Series
Touch Safe Cover
4:
Not included (IP00)
7:
Included (IP20)
Rated Load Current
0:
10 Amps
1:
25 Amps
Thermal Pad
Blank:
Not included
H:
Included
8413
4
9
1
U
0
H
1/4” QC output
terminals
(IP00 only)
Operating Voltage
9:
24-280 VAC/
Zero Voltage Turn-On
Required for valid part number
For options only and not required for valid part number
Control Voltage
0:
3-32 VDC
1:
90-280 VAC
4:
3-32 VDC 3/16” QC input
5:
90-280 VAC 3/16” QC input
7:
3-32 VDC 1/4” QC input
9:
90-280 VAC 1/4” QC input
OUTPUT SPECIFICATIONS
(1)
Description
Operating Voltage (47-63Hz) [Vrms]
Transient Voltage [Vdc]
(2)
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec]
Maximum Load Current [Arms]
(3)
Minimum Load Current [mArms]
Maximum 1 Cycle Surge Current (50/60Hz) [Apk]
1 Second surge current (Apk. Ta=25°C)
50/60 Hz
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Thermal Resistance Junction to Case (Rjc) [°C/W]
Maximum 1/2 Cycle I² t for Fusing (50/60Hz) [A² sec]
Minimum Heat Sink for Rated Current @ 40°C
[°C/W]
10 A
24-280
600
0.1
500
10
100
90/100
30
1.5
2.2
41/42
3
25 A
24-280
600
0.1
500
25
100
239/250
75
1.3
0.8
285/259
1.5
Do not forget to visit us at:
www.crydom.com
Copyright © 2016 Crydom Inc. Specifications subject to change without notice.
Datasheet
INPUT SPECIFICATIONS
(1)
Description
Control Voltage Range
Maximum Reverse Voltage
Minimum Turn-On Voltage
Must Turn-Off Voltage
Minimum Input Current (for on-state)
Maximum Input Current [mA]
Nominal Input Impedance [Ohms]
Maximum Turn-On Time [msec]
Maximum Turn-Off Time [msec]
Panel Mount
DC Control
3-32 VDC
(4)
-32 VDC
3 VDC
1 VDC
9.5 mA
14mA
Current Limited
1/2 Cycle
(6)
1/2 Cycle
AC Control
90-280 VAC
(5)
-
90 VAC
10 VAC
5 mA
8.5 mA
20
30
GENERAL SPECIFICATIONS
(1)
Description
Dielectric Strength, Input to Output (50/60Hz)
Dielectric Strength, Input/Output to Ground (50/60Hz)
Minimum Insulation Resistance (@ 500 VDC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
(7)
Ambient Storage Temperature Range
Weight (typical)
Housing Material
Baseplate Material
Input Terminal Screw Torque Range (in-lb/Nm)
Load Terminal Screw Torque Range (in-lb/Nm)
SSR Mounting Screw Torque Range (in-lb/Nm)
Humidity
per IEC60068-2-78
LED Input Status Indicator
MTBF (Mean Time Between Failures) at 40°C ambient temperature
(8)
MTBF (Mean Time Between Failures) at 60°C ambient temperature
(8)
Parameters
4000 Vrms
2500 Vrms
10
9
Ohms
8 pF
-40 to 80 °C
-40 to 100 °C
2.46 oz (70 g)
UL94 V-0
Aluminum
13-15 /1.5-1.7
18-20 / 2-2.2
18-20 / 2-2.2
93% non-condensing
Green
11,641,553 hours (1,328 years)
7,210,376 hours (823 years)
GENERAL NOTES
(1)
All parameters at 25°C unless otherwise specified.
(2)
Output will self trigger between 450-600Vpk not suitable for capacitive loads.
(3)
Heat sinking required, see derating curves.
(4)
Increase minimum voltage by 1V for operations from -20 to -40°C.
(5)
For ambient temperatures above 40°C the maximum control voltage must not exceed 250 VAC.
(6)
Turn-on time for Instantaneous turn-on versions is 0.1 msec.
(7)
AC models operating range is -20 to 80°C.
(8)
All parameters at 50% power rating and 100% duty cycle (contact Crydom tech support for detailed report).
(9)
Load can be wired to either SSR output terminal 1 or 2.
(10)
For single surge pulse Tc=25°C; Tj=125°C. For AC Output SSRs, AC Rms value of surge current equals the peak value divided by √2 (1.414).
For additional information or specific questions, contact Crydom Technical Support.
Do not forget to visit us at:
www.crydom.com
Copyright © 2016 Crydom Inc. Specifications subject to change without notice.
Datasheet
WIRING DIAGRAM
AC
V
Panel Mount
Load
(9)
1 ( )
2 ( )
Terminals
Recommended Wire Sizes
Wire Size
(Solid / Stranded)
24 AWG (0.2 mm
2
) / 0.2 [minimum]
2 x 12 AWG (3.3 mm
2
) / 3.3 [maximum]
20 AWG (0.5 mm
2
) / 0.518 [minimum]
Output
2 x 10 AWG (5.3 mm
2
)
/ 5.3
2 x 8 AWG (8.4 mm
2
) / 8.4 [maximum]
Wire Pull-Out
Strength (lb)[N]
10 [44.5]
90 [400]
30 [133]
110 [490]
90 [400]
Input
1
OUTPUT
S O L I D S TAT E R E L AY
2
4
INPUT
3
4 (– / )
3 (+ / )
EQUIVALENT CIRCUIT BLOCK DIAGRAMS
GNA5 Series DC Control
-DC
4
1
AC
14
Input Current vs Input Voltage
Standard Regulated DC Input
Input Current (mA)
12
10
8
6
4
2
0
0
5
10
Trigger
Circuit
+DC
3
Current
Limiter
OUTPUT
2
AC
INPUT
DC Input Voltage
15
20
25
30
35
GNA5 Series AC Control
Current
Limiter
7
Input Current vs Input Voltage
Standard Regulated AC Input
Input Current (mA)
AC
4
1
AC
6
5
4
3
2
1
0
0
50
100
INPUT
AC/DC
Converter
Trigger
Circuit
AC
3
OUTPUT
2
AC
AC Input Voltage
150
200
250
300
Do not forget to visit us at:
www.crydom.com
Copyright © 2016 Crydom Inc. Specifications subject to change without notice.
Datasheet
Tolerances: ±0.02 in / 0.5 mm
All dimensions are in: inches [millimeters]
Panel Mount
MECHANICAL SPECIFICATIONS
(1)
Screw Termination, IP00
1.1
[27.9]
0.49
[12.4]
Mounting
Hole/Slot
0.19 [4.9]
DIA.
0.89
[22.6]
1.10
[27.9]
0.49
[12.4]
Screw Termination, IP20
Mounting
Hole/Slot
0.19 [4.9]
DIA.
1.88
[47.6]
1.7
[43.2]
2.25
[57.3]
1.88
[47.6]
1.7
[43.2]
2.32
[58.8]
2.25
[57.3]
1.0
[25.4]
1.75
[44.5]
1.0
[25.4]
1.75
[44.5]
1.22
[30.9]
Quick Connect, Input 3/16”, Output 1/4”
Mounting
Hole/Slot
0.19 [4.9]
DIA.
1.1
[27.9]
0.49
[12.4]
Faston
Terminal
0.25 x 0.032
1.32
[33.6]
Mounting
Hole/Slot
0.19 [4.9]
DIA.
Quick Connect, Input 1/4”, Output 1/4”
1.1
[27.9]
0.49
[12.4]
Faston
Terminal
0.25 x 0.032
1.32
[33.6]
(2 Places)
(4 Places)
1.88
[47.6]
2.22
[56.3]
1.7
[43.2]
2.25
[57.2]
1.88
[47.6]
2.34
[59.5]
1.7
[43.2]
2.25
[57.2]
1.0
[25.4]
1.75
[44.5]
(2 Places)
Faston
Terminal
0.187x0.02
1.24
[31.6]
1.0
[25.4]
1.75
[44.5]
1.32
[33.6]
Do not forget to visit us at:
www.crydom.com
Copyright © 2016 Crydom Inc. Specifications subject to change without notice.
Datasheet
THERMAL DERATE INFORMATION
10 A
2°C/W
10
Load Current (Amps)
Load Current (Amps)
8
6
4
2
0
20
30
40
50
60
Ambient Temperature (ºC)
70
80
3°C/W
5°C/W
No Heat Sink*
25
20
15
10
5
0
20
30
40
50
60
Ambient Temperature (ºC)
70
80
(i)
SSR metal base plate acting as heat sink, it must be exposed to free ambient air.
Panel Mount
25 A
1.5ºC/W
2ºC/W
3ºC/W
SURGE CURRENT INFORMATION
Single Pulse
(10)
10 A
90
80
70
60
50
40
30
20
10
0
0.01
Surge Current (Amp) AC Peak
Surge Current (Amp) AC Peak
250
200
150
100
50
0
0.01
0.1
25 A
0.1
1
10
1
10
Surge Duration (sec)
Surge Duration (sec)
AGENCY APPROVALS
EN60950-1: Meets the requirements of sections1.5: 1,7: 2.9: 2.10.5.3: 4.2: 4.5: 4.7:
IEC 61000-4-2 Electrostatic Discharge Level 3
IEC 61000-4-4 Electrically Fast Transients Level 3
IEC 61000-4-5 Electrical Surges Level 3
E46203
LR 38595
Do not forget to visit us at:
www.crydom.com
Copyright © 2016 Crydom Inc. Specifications subject to change without notice.
