ESQT–115–02–F–D–500
F-208
ESQT–130–03–M–Q–400
TM
ESQT–110–02–G–Q–750
2mm ELEVATED SOCKET
SPECIFICATIONS
For complete specifications
see www.samtec.com?ESQT
ESQT
SERIES
Mates with:
TMMH, TMM, MTMM,
MMT, TW, LTMM,
ZLTMM, ESQT, TCMD
High Retention
Contacts
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
Phosphor Bronze
Plating:
Sn or Au over
50µ" (1,27µm) Ni
AMBIENT CURRENT
Current Rating:
RATING
TEMP
3A @ 80°C ambient
Operating Temp Range:
5.5A
20°C
-55°C to +125°C
Contact Resistance:
5A
40°C
10 mΩ max
4A
60°C
Insertion Depth:
(2,62mm) .103" to
3A
80°C
(5,03mm) .198" with
(0,38mm) .015" wipe
Max Cycles:
100 with 10µ" (0,25µm) Au
Insertion Force:
(Single contact only)
Note:
This Series is
4oz (1,11N) avg.
non-standard, non-returnable.
Withdrawal Force:
(Single contact only)
3oz (0,83N) avg.
NO. PINS
RoHS Compliant:
Yes
PER ROW
APPLICATION
SPECIFIC OPTION:
NOTEBOOK 2.5" DISK
DRIVE INTERFACE
(2,00mm)
.0787" pitch
Call for part number.
ESQT
1
Processing:
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
BODY
HEIGHT
OTHER
OPTION
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x for -S,
-D & -Q (230°C for 60 seconds
only for -T, -5 & -6)
Lead–Free Solderable:
Yes, for -S, -D & -Q
(Wave only for -T, -5 & -6)
–S
–G
= 20µ" (0,51µm) Gold
(Recommended for
self-nesting)
= Single
Row
–“XXX”
= Body
Height
(in inches)
(7,87mm)
.310"
minimum for
–S, –D, –Q
(9,53mm)
.375"
minimum for
–T, –5, –6
–“XXX”
= Polarized
Position
(Indicate
position
number)
02 thru 50
–D
= Double
Row
Also Available
Surface
Mount
See SQW and
TLE Series.
300
–M
= 20µ" (0,51µm)
Gold on contact,
Matte Tin on tail
–T
= Triple
Row
No. of positions x
(2,00) .0787 + (0,30) .012
06
–L
(2,00) No. of
.0787 rows
TYP
x
(2,00)
.0787
= 10µ" (0,25µm)
Gold on contact,
Matte Tin on tail
–Q
= Quad
Row
Low
Profile
See CLT Series.
ALSO AVAILABLE
–F
= Gold flash on contact,
Matte Tin on tail
–5
= Five
Row
High
Reliability
See SMM Series.
295
01
–6
= Six
Row
Right
Angle
See SQW Series.
(6,35)
.250
(1,52)
.060
A
BODY
HEIGHT
TAIL
(1,27)
.050
MIN
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
(Not recommended for stack
through applications)
PC104+
Sockets
See ESQT-368
and PTHF Series.
LEAD
STYLE
A
MAX MAX BODY
TAIL
HEIGHT
(20,32)
.800
(10,36)
.408
– 02
(21,59) (13,72)
.850
(0,50) .020 SQ
(2,00) .0787
–03
.540
(11,63) (3,76)
.458
.148
