REVISIONS
REV.
A
B
F
ECO. NO
893
1126
1811
DESCRIPTION
INITIAL RELEASE
UPDATE SPECIFICATIONS
UPDATE P/N CODING, POSITION TABLE,
SPECIFICATIONS, TOLERANCE BLOCK
DATE
1/13/2006
9/12/2006
1/09/09
BY
TT
MV
JH
F
C
E
E
.079 2.00
.315 8.00
D
.079±.004 2.00±0.10
.079 2.00
.236 6.00
D
.079±.002 2.00±0.05
B±.012 [ .30]
.031 0.80
A±.004 [ .10]
RECOMMENDED PCB LAYOUT
C
.072 1.82
.189 4.80
.250 6.35
C
.094±.008 2.40±0.20
B
A
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: SEE PART NUMBER CODING.
4. CURRENT RATING: 2 AMPS
5. INSULATOR RESISTANCE: 5000 MEGOHMS MIN.
6. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
7. DIELECTRIC WITHSTANDING: AC 500V.
8. OPERATING TEMPERATURE: -40° C TO +105° C.
9. *PROCESSING TEMP.: 260° C FOR 10 SECS MAX.
*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT
INSULATOR. HIGHER PROCESSING TEMPERATURES MAY BE USED,
PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB, AND INSULATOR
DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.
8
7
6
.020±.002 0.50±0.05
.079±.002 2.00±0.05
A±.008 [ .20]
02-20, 0.20mm MAX.
21-40, 0.30mm MAX.
.020±.002 0.50±0.05
.236 6.00
.079±.004 2.00±0.10
B
Pb
R
oHS COMPLIANT
5
4
DIMENSIONS ARE IN INCHES[MM]
TOLERANCES:
ANGULAR: 5
.X= .012 [.30]
.XX= .008 [.20]
.XXX= .006 [.15]
SURFACE FINISH: 63 Ra
UNLESS OTHERWISE SPECIFIED:
DRAWN
DATE
NAME
1/10/09
JH
REMOVE ALL BURRS AND SHARP EDGES .010 MAX
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
HEADER, FEMALE 2mm CC, 4 ROWS, ST
A
NPxNxx4EFCN-RC
SIZE DWG. NO.
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5M-1994
3
2
SCALE: 12:1
1
C
REV
10665
C
SHEET 1 OF 1
FILE NAME: Z:\COMPONENTS\Taiwan\10665, NPxNxx4EFCN-RC PRINT: 3/4/2009
