CONTENTS
General Information
Technical terms explanation
Application note-safety conditions
Product Code System and Date Code
Packaging
Ceramic capacitors
Contents
KHB series
Class 2 General purpose
KHC series
Class 1 General purpose
KJN series
Y1 (250Vac/400Vac) / X1 (440Vac)
KJY series
Y2 (250Vac) / X1 (400Vac)
1 - 2KVdc
1 - 2KVdc
Page
2 - 13
2
2
11
12
13 - 23
14
17
19
21
23
Statements of suitability for certain applications are based on our knowledge of typical operating conditions for such applications, but are not intended to constitute –
and we speci cally disclaim – any warranty concerning suitability for a speci c customer application or use. This information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any technical advice inferred from this information or otherwise
provided by us with reference to the use of our products is given gratis, and we assume no obligation or liability for the advice given or results obtained.
1
GENERAL INFORMATION
TECHNICAL TERMS EXPLANATION
Rated capacitance
Capacitance referred to 1 kHz, 20
±
1°C, 65
±
2% of relative humidity and 96 ±10 kPa.
In case of doubt please refer to IEC 60068-1, sub-clause 5.2.
Capacitance tolerance
Admitted capacitance deviation from the rated capacitance.
Rated temperature (T
R
)
The maximum ambient temperature surrounding the capacitor or hottest contact point (e.g.: tracks), whichever is
higher, at which the rated voltage, Vdc or Vac at 50 Hz, may be continuously applied.
Rated voltage (V
R
)
The maximum direct voltage or the maximum r.m.s. alternating voltage (50Hz) or the peak value of a pulse voltage
which may be continuously applied to a capacitor at any temperature between the lower category temperature
and the rated temperature.
Climatic category
The climatic category which the capacitor belongs to is expressed in numbers (standard IEC 60068-1:
e.g.: 25/125/21).
The first number represents the lower category temperature (e.g.: -25°C); the second number the upper category
temperature (e.g.: +125°C) and the third number represents the number of days relevant to the damp heat test
(e.g.: 21 days).
Dissipation factor (tg
δ
)
The dissipation factor is the ratio between the resistive and the reactive part of the impedance of the capacitor
submitted to a sinusoidal voltage of specified frequency.
Insulation resistance (Ir)
The insulation resistance is the ratio between an applied D.C. voltage and the resulting leakage current after a
minute of charge. It is expressed in MΩ.
APPLICATION NOTES - SAFETY CONDITIONS
1. Across-the-line and interference suppression applications
1.1 When a capacitor is used for this type of application it may be subject to a mains voltage on a
permanent basis and to surges caused, for example, by lightning, power commutations etc.
In these working conditions the capacitor must be a \component with a safety margin able to satisfy
