Preview

FA2-NESP-C00-0: DescriptionCONN FAKRA PLUG STR 50 OHM CRIMP; CategoryThe connector; File Size170KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

FA2-NESP-C00-0 Overview

CONN FAKRA PLUG STR 50 OHM CRIMP

FA2-NESP-C00-0 Parametric

Parameter Name	Attribute value
Connector style	SMB，Fakra
Connector type	Plug, male pin
Contact termination	crimp
Protective termination	crimp
impedance	50 ohms
Installation type	Panel mounting
Installation features	flange
cable set	RG-58/RG-174 composite design
Fastening type	Lock pin slide
Frequency - maximum	4GHz
Number of ports	2
characteristic	Code E
Shell color	green leaves
Intrusion protection	-
include	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing
Matrix material	brass
substrate surface	nickel
Center contact plating	gold
dielectric materials	Polytetrafluoroethylene (PTFE)
Operating temperature	-40°C ~ 100°C
center contact material	brass
Number of patches	100
Insertion loss	0.3dB

Preview

Download Datasheet

View All

FA2-NESP-C00-0 Related Products

	FA2-NESP-C00-0	FA2-NASP-C00-0	FA2-NBSP-C00-0	FA2-NCSP-C00-0	FA2-NDSP-C00-0	FA2-NFSP-C00-0	FA2-NZSP-C00-0
Description	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP	CONN FAKRA PLUG STR 50 OHM CRIMP
Connector style	SMB，Fakra	SMB，Fakra	SMB，Fakra	SMB，Fakra	SMB，Fakra	SMB，Fakra	SMB，Fakra
Connector type	Plug, male pin	Plug, male pin	Plug, male pin	Plug, male pin	Plug, male pin	Plug, male pin	Plug, male pin
Contact termination	crimp	crimp	crimp	crimp	crimp	crimp	crimp
Protective termination	crimp	crimp	crimp	crimp	crimp	crimp	crimp
impedance	50 ohms	50 ohms	50 ohms	50 ohms	50 ohms	50 ohms	50 ohms
Installation type	Panel mounting	Panel mounting	Panel mounting	Panel mounting	Panel mounting	Panel mounting	Panel mounting
Installation features	flange	flange	flange	flange	flange	flange	flange
cable set	RG-58/RG-174 composite design	RG-58/RG-174 composite design	RG-58/RG-174 composite design	RG-58/RG-174 composite design	RG-58/RG-174 composite design	RG-58/RG-174 composite design	RG-58/RG-174 composite design
Fastening type	Lock pin slide	Lock pin slide	Lock pin slide	Lock pin slide	Lock pin slide	Lock pin slide	Lock pin slide
Frequency - maximum	4GHz	4GHz	4GHz	6GHz	4GHz	4GHz	4GHz
Number of ports	2	2	2	2	2	2	2
characteristic	Code E	Code A	Code B	Code C	Code D	Code F	Code Z
Shell color	green leaves	jet black	cream color	blue, signal	wine red purple	dark brown	blue, aqua
include	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing	7 pieces - 2 connectors, 2 contacts, 2 sleeves, 1 housing
Matrix material	brass	brass	brass	brass	brass	brass	brass
substrate surface	nickel	nickel	nickel	nickel	nickel	nickel	nickel
Center contact plating	gold	gold	gold	gold	gold	gold	gold
dielectric materials	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)
Operating temperature	-40°C ~ 100°C	-40°C ~ 100°C	-40°C ~ 100°C	-40°C ~ 100°C	-40°C ~ 100°C	-40°C ~ 100°C	-40°C ~ 100°C
center contact material	brass	brass	brass	brass	brass	brass	brass
Number of patches	100	100	100	100	100	100	100
Insertion loss	0.3dB	0.3dB	0.3dB	0.3dB	0.3dB	0.3dB	0.3dB
