RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
CXW
CXW
SERIES
105℃ 5000 hours, Ultra Miniaturized
・
Temperature Range : −40℃∼+105℃
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−40∼＋105℃
400∼500Vdc
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
I＝3
CV (After 5 minutes application of rated voltage)
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
(Vdc)
tanδ
Dissipation Factor(MAX)
400∼450
0.20
500
0.25
（20℃, 120Hz）
(tanδ)
After applying rated voltage with rated ripple current for 5000 hours at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Within ±20％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
(Vdc)
Z
（−25℃） （20℃）
/Z
400
5
420∼500
6
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
Coefficient
◆DIMENSIONS
1k
1.40
10k≦
1.50
SLEEVE(PET)
(mm)
φd
60(50) 120
0.80
1.00
500
1.25
◆OPTION
Code
PET Sleeve
（−40∼＋105℃）
L+α MAX
15MIN
4MIN
φD+0.5MAX
EFR ※
φD
φd
F
α
8
10
0.6
12.5
14.5
16
0.8
18
※
PET Sleeve −25∼+105℃
（EFC） also available, please consult our sales offices.
is
3.5
5.0
2.0
7.5
◆PART NUMBER
□□□
Rated Voltage
CXW
Series
□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
F
±0.5
