9
8
7
6
5
4
3
2
1
A
E
C
±
.025
C
±
.64
SEE NOTE 9
CIRCUITS
DIM A
CIRCUIT 1 I.D.
2
3
4
.623
±
.010
(15.82
±
0.25)
.918
±
.010
(23.32
±
0.25)
1.213
±
.010
(30.82
±
0.25)
1.508
±
.010
(38.30
±
0.25)
1.803+.010/-.015
(45.80 +0.25/-0.38)
2.393
±
.010
(60.78
±
0.25)
DIM B
.295
±
.006
(7.49
±
0.15)
.590
±
.008
(14.99
±
0.20)
.885
±
.008
(22.48
±
0.20)
1.180
±
.008
(29.97
±
0.20)
1.475
±
.010
(37.47
±
0.25)
2.065
±
.008
(52.45
±
0.20)
E
1.078
±
.015
27.38
±
0.38
1.033
±
.015
26.24
±
0.38
.188
±
.025
4.77
±
0.64
5
6
8
D
D
CIRCUIT 1
LAST CIRCUIT I.D.
SEE NOTE 8
BOTH TERMINAL
ORIENTATIONS
ARE ACCEPTABLE
C
.632
REF
16.05
C
B
NOTES:
1. MATERIAL: SEE CHART.
2. THIS CONNECTOR HOUSING FOR USE WITH 43375-**** TERMINALS.
B
3. THIS CONNECTOR HOUSING WILL MATE TO A-43160-*****, 43180-****,
AND 43680-**** HOUSINGS.
4. PRODUCT SPECIFICATION: PSX-44441-9999.
5. PACKAGING: PK-44441-001.
6. FOR V-0 AND GLOW-WIRE MATERIAL: PARTS CONFORM TO CLASS 'B'
REQUIREMENTS OF COSMETIC SPECIFICATION PS-45499-002 BUT,
MEETS CLASS 'C' REQUIREMENTS FOR BUBBLES, SINK AND DISCOLORATION.
7. TEXT ON PART IS FOR REFERENCE ONLY. TEXT AND TEXT LOCATION MAY VARY
DEPENDING ON PART NUMBER AND/OR TOOL.
A
8. LAST CIRCUIT I.D. NOT PRESENT ON 2 CIRCUIT PARTS.
9. DIMENSION C IS .600/(15.24) FOR 2 AND 8 CIRCUIT PARTS
DIMENSION C IS .632/(16.05) FOR ALL OTHER CIRCUIT SIZES.
10. THIS DRAWING REPLACES DRAWINGS SD-44441-*.
DOCUMENT STATUS
FORMAT: Eng-lega-master-tb-prod-B
REVISION: D
DATE: 2017/10/06
CROSS SECTION
WITH TERMINAL
NO SCALE
B
SYMBOLS
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
CURRENT REV DESC: UPDATE TOLERANCES
IN/MM
MM
2:1
INCH
±
±
GENERAL TOLERANCES
(UNLESS SPECIFIED)
EC NO:
604166
4 PLACES
±
3 PLACES
±
2 PLACES
±
1 PLACE
±
0.01
0.25
0.35
±
0.014
±
±
±
0.5 °
0 PLACES
±
ANGULAR TOL
DRWN: JBAUMERT
CHK'D:
MKIPPER
APPR:
FSMITH
INITIAL REVISION:
DRWN:
CSLAFTER
APPR:
JDFOX
THIRD ANGLE PROJECTION
DRAWING
2018/09/07
2018/09/12
2018/09/13
2016/12/28
2016/12/30
SERIES
44441 SABRE RECEPTACLE TPA HOUSING
A
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
444410000-SD
MATERIAL NUMBER
CUSTOMER
PSD
000
A1
P1
RELEASE DATE
2018/09/13
17:17:27
=
0
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
B-SIZE
44441
SEE CHART
GENERAL MARKET
1 OF 2
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
CIRCUITS ITEM NUMBER
MATERIAL
COLOR
NATURAL
(TRANSLUCENT)
BLACK
E
2
3
4
5
6
2
3
4
5
6
8
2
3
4
5
6
8
44441-1002
44441-1003
44441-1004
44441-1005
44441-1006
44441-2002
44441-2003
44441-2004
44441-2005
44441-2006
44441-2008
44441-3002
44441-3003
44441-3004
44441-3005
44441-3006
44441-3008
POLARIZATION LAYOUT
E
PA66 NYLON, UL94V-2
PA66 NYLON, UL94V-2
PA66 NYLON, UL94V-0
BLACK
2-CKT.
5-CKT.
D
D
PA6 NYLON, UL94V-2 IEC 60335-1
GLOW WIRE CAPABLE
BLACK
3-CKT.
6-CKT.
C
C
4-CKT.
B
8-CKT.
B
SYMBOLS
=
0
=
0
=
0
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
CURRENT REV DESC: UPDATE TOLERANCES
IN/MM
MM
2:1
INCH
±
±
GENERAL TOLERANCES
(UNLESS SPECIFIED)
EC NO:
604166
A
=
0
=
0
=
0
=
0
=
0
4 PLACES
±
3 PLACES
±
2 PLACES
±
1 PLACE
±
0.01
0.25
0.35
±
0.014
±
±
±
0.5 °
0 PLACES
±
ANGULAR TOL
DRWN: JBAUMERT
CHK'D:
MKIPPER
APPR:
FSMITH
INITIAL REVISION:
DRWN:
CSLAFTER
APPR:
JDFOX
THIRD ANGLE PROJECTION
DRAWING
2018/09/07
2018/09/12
2018/09/13
2016/12/28
2016/12/30
SERIES
44441 SABRE RECEPTACLE TPA HOUSING
A
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
444410000-SD
MATERIAL NUMBER
CUSTOMER
PSD
000
A1
DOCUMENT STATUS
FORMAT: Eng-lega-master-tb-prod-B
REVISION: D
DATE: 2017/10/06
P1
RELEASE DATE
2018/09/13
17:17:27
C
=
0
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
B-SIZE
44441
SEE CHART
GENERAL MARKET
2 OF 2
9
8
7
6
5
4
3
2
1
