and low distortion amplification for 75 Ω customer
premises equipment (CPE).
The MAAM-011117 incorporates a power-down
function to reduce the overall current consumption to
less than 4 mA for standby operation.
The MAAM-011117 is packaged in a 2 mm 8-lead
package and requires a minimal number of off-chip
components resulting in a highly integrated low cost
solution.
Pin Configuration
3
Pin No.
1
2
3
4
5
Pin Name
I
ADJ
N/C
V
CTRL
N/C
RF
IN
N/C
N/C
RF
OUT
Paddle
4
Description
Current Control
No Connection
Power Down
LO: 0 V; HI: 3.3 V
No Connection
RF Input (75 Ω)
No Connection
No Connection
RF Output (75 Ω)
RF and DC Ground
Ordering Information
1,2
Part Number
MAAM-011117-TR3000
MAAM-011117-001SMB
Package
3000 piece reel
Sample Board
6
7
8
9
1. Reference Application Note M513 for reel size information.
2. All sample boards include 5 loose parts.
3. MACOM recommends connecting unused package pins to
ground.
4. The exposed pad centered on the package bottom must be
connected to RF and DC ground.
* Restrictions on Hazardous Substances, European Union Directive 2011/65/EU.
1
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MAAM-011117
75
Ω,
5 V RF Amplifier
50 - 2700 MHz
Electrical Specifications: T
A
= 25°C, Freq: 50
- 2700 MHz, V
DD
= +5 Volts, Z
0
= 75 Ω
Parameter
Gain
Gain Flatness
Noise Figure
Reverse Isolation
Input Return Loss
Output Return Loss
Test Conditions
—
—
50 MHz - 1.2 GHz
1.2 GHz - 2.7 GHz
—
—
—
Swept frequency: 50 MHz - 870 GHz,
IM Tone at 100 MHz
Output IP2
5
Input tones at 2.5 GHz and 2.6 GHz,
IM Tone at 100 MHz
Input tones at 1.0 GHz and 1.1 GHz,
Input Power = -15 dBm, Output tone 2.1 GHz
Output IP3
5
Composite Triple Beat, CTB
Composite Second Order, CSO
Cross Modulation, XMOD
Output P1dB
I
DD
Swept frequency from 50 MHz - 870 MHz
Swept frequency from 870 MHz - 2 GHz
Swept frequency from 2.0 - 2.7 GHz
79 Channels, +15 dBmV / Channel at I/P
79 Channels, +15 dBmV / Channel at I/P
79 Channels, +15 dBmV / Channel at I/P
1 GHz
Power Up: V
DD
= 5 V, V
CTRL
= 3.3 V
Power Down: V
DD
= 5 V, V
CTRL
= 0 V
Units
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
dBc
dBc
dBc
dBm
mA
Min.
14.7
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Typ.
16
±0.5
2.7
3.0
20
12
16
58
45
50
35
30
26
-75
-65
-65
19.5
85
3.5
Max.
17.2
—
—
—
—
—
—
—
—
—
—
—
—
—
105
—
Rev. V3
5. Measured with two tones, 100 MHz spacing, -15 dBm input power per tone.
V
CTRL
Logic Voltages (V
DD
= +5 V)
Parameter
V
CTRL
Logic Low
V
CTRL
Logic High
I
CTRL
Logic Low
I
CTRL
Logic High
Units
V
V
mA
mA
Min
-0.5
1.2
-0.5
-0.5
Typ
0
3.3
—
—
Max
0.2
3.47
1
1
Absolute Maximum Ratings
6,7,8
Parameter
Input Power
Operating Voltage
Operating Temperature
Storage Temperature
Absolute Maximum
7 dBm
10 volts
-40°C to +85°C
-65°C to +150°C
Handling Procedure - Static Sensitivity
Gallium Arsenide Integrated Circuits are sensitive to
electrostatic discharge (ESD) and can be damaged by
static electricity. Proper ESD control techniques should
be used when handling these HBM Class 0A, CDM
Class II devices.
6. Exceeding any one or combination of these limits may cause
permanent damage to this device.
7. MACOM does not recommend sustained operation near these
survivability limits.
8. Junction Temperature (T
J
) = T
C
+
Өjc
* (V * I)
Typical thermal resistance (Өjc) = 73° CW.
a) For T
C
= +25°C,
T
J
= 57°C @ 5 V, 85 mA
b) For T
C
= +85°C,
T
J
= 117°C @ 5 V, 85 mA
2
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MAAM-011117
75
Ω,
5 V RF Amplifier
50 - 2700 MHz
Recommended Board Layout
Rev. V3
Schematic Including Off-Chip Components
PCB Land Pattern
2x2mm PDFN, 8-LEAD
Metal
Solder Mask
1.0
Parts List
9
Component
Solder mask
extended
0.05mm on pads
0.3
Value
10 nF
220 pF
0.7 pF
0.2 pF
100 nF
1 µF
510 Ω
510 kΩ
Ferrite Bead
3.0 nH
3.3 nH
Package
0402
0402
0402
0402
0603
0603
0402
0402
0402
0402
0402
C1 - C3
C4
C5
C6
C7
2mm Outline
0.25
0.50
2.5
0.50
C8
R1
R2
L1
L2
Thermal/GND Pad
10 vias
0.2-0.3
Solder mask
reduced 0.05mm
on GND pad
L3
9. Ferrite Bead from Murata, part number BLM15HD182SN.
3
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MAAM-011117
75
Ω,
5 V RF Amplifier
50 - 2700 MHz
Typical Performance Curves: V
DD
= +5 V; I
DD
= 85 mA, Power-Up Mode
Gain to 2.7 GHz
20
19
18
17
S21 (dB)
Rev. V3
Gain to 5 GHz
20
+25 °C
-40 °C
+85 °C
15
10
5
S21 (dB)
+25 °C
-40 °C
+85 °C
16
15
0
-5
-10
-15
-20
14
13
12
11
10
0.0
0.3
0.6
0.9
1.2
1.5
1.8
Frequency (GHz)
2.1
2.4
2.7
0.0
1.0
2.0
3.0
Frequency (GHz)
4.0
5.0
Input Return Loss
0
+25 °C
-40 °C
+85 °C
Output Return Loss
0
+25 °C
-40 °C
+85 °C
-5
-5
S11 (dB)
-15
S22 (dB)
-10
-10
-15
-20
-20
-25
0.0
0.3
0.6
0.9
1.2
1.5
1.8
Frequency (GHz)
2.1
2.4
2.7
-25
0.0
0.3
0.6
0.9
1.2
1.5
1.8
Frequency (GHz)
2.1
2.4
2.7
Noise Figure
8
7
6
Reverse Isolation
0
+25 °C
-40 °C
+85 °C
-5
-10
+25 °C
-40 °C
+85 °C
Noise Figure (dB)
5
S12 (dB)
4
3
2
-15
-20
-25
1
0
-30
0.0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
2.7
0.0
0.3
0.6
0.9
4
Frequency (GHz)
1.2
1.5
1.8
Frequency (GHz)
2.1
2.4
2.7
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.macom.com
for additional data sheets and product information.
For further information and support please visit:
https://www.macom.com/support
MAAM-011117
75
Ω,
5 V RF Amplifier
50 - 2700 MHz
Typical Performance Curves: V
DD
= +5 V; I
DD
= 85 mA, Power-Up Mode
CSO Lower
79ch, +15 dBmV/ch Flat Input Power
95
90
85
CSO Lower (dBc)
Rev. V3
CSO Upper
79ch, +15 dBmV/ch Flat Input Power
95
+25 °C
+85 °C
-40 °C
CSO Upper (dBc)
90
85
80
75
70
65
+25 °C
+85 °C
-40 °C
80
75
70
65
60
0
100
200
300
400
Frequency (MHz)
500
600
60
0
100
200
300
400
Frequency (MHz)
500
600
CTB
79ch, +15 dBmV/ch Flat Input Power
90
85
+25 °C
+85 °C
-40 °C
Cross Modulation
79ch, +15 dBmV/ch Flat Input Power
80
+25 °C
+25 °C
-40 °C
75
80
XMOD (dBc)
CTB (dBc)
70
75
70
65
60
0
100
200
300
400
Frequency (MHz)
500
600
65
60
55
0
100
200
300
400
Frequency (MHz)
500
600
5
