Type 5ST / 5STP
5STD0106
W5STD0405-A1
5 x 20mm Glass Tube
RoHS Compliant
Time-lag Fuse Series (Low Breaking Capacity)
Catalog
Number
RoHS
Suffix
Ampere
Rating
Typical
Volt-drop Melting I
2
T Melting I
2
T Maximum
Cold
@100%
In
< 10 mSec @10
In
Power
Resistance
Dissipation
(ohm) (Volt) max. (A
2
Sec)
(A
2
Sec)
(W)
5ST (P) 63
5ST (P) 80
5ST (P) 100
5ST (P) 125
Rated Current
63mA to 100mA
125mA to 12.5A
1.5
In
2.1
In
MIN
MAX
2.75
In
MIN
4
In
10
In
MAX MIN MAX MIN MAX
Electrical Characteristics
(IEC-127-2 STANDARD SHEET 3)
5ST (P) 160
5ST (P) 200
5ST (P) 250
5ST (P) 315
5ST (P) 400
5ST (P) 500
5ST (P) 630
5ST (P) 800
5ST (P) 1
5ST (P) 1.25
5ST (P) 1.6
5ST (P) 2
5ST (P) 2.5
5ST (P) 3.15
5ST (P) 4
5ST (P) 5
5ST (P) 6.3
5ST (P) 8
5ST (P) 10
5ST (P) 12.5
1
1
hr.
2
2
min.
200
600
ms
10
10
sec
40
150
ms
3
3
sec
10
20
ms
300
300
ms
Approvals
sd
m
r
Sc
c
Amp range / Volt @ I.R.
ability
Safety Agency Approvals
s
d
m
r
c
Certificate No. 0045061
License No. 40000507
Certificate No. EM231
Recognized File No. E20624
63mA - 10A / 250V AC@ 35A or
10
In
whichever is greater
63mA - 6.3A / 250V AC@ 35A or
10
In
whichever is greater
63mA - 6.3A / 250V AC@ 35A or
10
In
whichever is greater
S
Acceptance File No. LR39772
Licence No. 2003010207030316
RoHS Compliant Product
For RoHS Compliant Version, add suffix “R” after catalog number
Operating Temperature
-55ºC to +125ºC
Physical Specification
Materials
Glass body / Nickel Plated Brass Caps
Lead wire:
Tin plated copper alloy,
Diameter 0.032", 6.3A and less
Diameter 0.040", 8A and above
Marking
On fuse:
“bel”, “T”, “Current Rating”, “L”, “250V” ,
“Appropriate Safety Logos”, “✔” (RoHS Version)
On label:
“bel”, “5ST” or “5STP”, “Current Rating”, “Voltage
Rating”, “Interrupting Rating”, “Appropriate Safety Logos”
and “
”+ suffix “R” for RoHS Version
Packaging
1.In bulk:
5ST
- 1,000 pcs per box;
5STP
- 500 pcs per box
2. On Axial Tape & Reel:
1,500 pcs per reel
3. Tape & Reel specification:
per EIA-296-E & IEC 286-1
@ 10mm Pitch and 63.5mm inside Tape Spacing
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
-
R
63mA
80mA
100mA
125mA
160mA
200mA
250mA
315mA
400mA
500mA
630mA
800mA
1A
1.25A
1.6A
2A
2.5A
3.15A
4A
5A
6.3A
8A
10A
12.5A
23.9
15.7
10.3
6.8
4.4
2.9
1.9
1.3
0.82
0.54
0.22
0.15
0.095
0.06
0.04
0.03
0.02
0.018
0.014
0.011
0.008
0.006
0.005
0.004
2.77
2.24
1.82
1.47
1.19
0.97
0.78
0.63
0.51
0.42
0.17
0.15
0.13
0.09
0.09
0.08
0.07
0.07
0.06
0.06
0.06
0.06
0.06
0.06
0.008
0.015
0.03
0.05
0.08
0.15
0.26
0.46
0.81
1.4
0.9
1.6
2.4
4.1
6.9
12
20
33
56
95
160
260
439
490
0.021
0.036
0.06
0.11
0.19
0.33
0.58
1.01
1.76
3.1
1.5
2.5
3.3
5.5
8.9
15
24
39
64
105
173
282
461
679
0.28
0.29
0.30
0.30
0.31
0.32
0.32
0.33
0.34
0.34
0.18
0.20
0.17
0.19
0.23
0.26
0.31
0.36
0.42
0.49
0.57
0.8
1.0
1.7
Consult manufacturer for other ratings
Mechanical Dimensions
0.787"
±
0.02"
(20
±
0.5mm)
0.20"
±
0.004"
(5.1
±
0.1mm)
Specifications subject to change without notice
5ST
1.5"
±
0.08"
(38.1
±
2mm)
0.827"
±
0.02"
(21.0
±
0.5mm)
0.217"
±
0.004"
(5.5
±
0.1mm)
5STP
SEE LEAD SIZE LISTED IN “ MATERIAL”
ORDERING INFORMATION SEE LAST 2 PAGES
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 • Tel: 201-432-0463 • Fax: 201-432-9542 • E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
43
Type 5ST / 5STP
5 x 20mm Glass Tube
RoHS Compliant
W5STC0405-A1
Time-lag Fuse Series (Low Breaking Capacity)
5STC1005
E5STC1005A1
5ST / 5STP - TIME CURRENT CHARACTERISTIC CURVE
-
63mA
-
80mA
-
100mA
-
125mA
-
160mA
-
200mA
-
250mA
-
315mA
-
400mA
-
500mA
-
630mA
-
800mA
-
1A
-
1.25A
-
1.6A
-
2A
-
2.5A
-
3.15A
-
4A
-
5A
-
6.3A
-
8A
-
10A
-
12.5A
10000
1000
TIME IN SECONDS
100
10
1
0.1
0.01
0.01
0.1
1
10
100
1000
CURRENT IN AMPERES
NOTE - see important information under “User Guide”on P.08
Corporate Office
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
Far East Office
Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706
European Office
Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K
Tel: 44-1772-556601
Fax: 44-1772-888366
Specifications subject to change without notice
