EG-2101CA 125.0000M-DCHL3 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> EG-2101CA 125.0000M-DCHL3

Preview

EG-2101CA 125.0000M-DCHL3: DescriptionOSC SO 125MHZ LVPECL SMD; CategoryPassive components; File Size87KB，2 Pages; ManufacturerEPSON; Websitehttp://www.epsondevice.com; Environmental Compliance

Download Datasheet Parametric View All

EG-2101CA 125.0000M-DCHL3 Overview

OSC SO 125MHZ LVPECL SMD

EG-2101CA 125.0000M-DCHL3 Parametric

Parameter Name	Attribute value
type	SO（SAW）
frequency	125MHz
Function	enable/disable
output	LVPECL
Voltage - Power	3.3V
frequency stability	±100ppm
Absolute pulling range (APR)	-
Operating temperature	0°C ~ 70°C
Current - Power (maximum)	60mA
grade	-
Installation type	surface mount
Package/casing	6-SMD, no leads
size/dimensions	0.276" long x 0.197" wide (7.00mm x 5.00mm)
Height - Installation (maximum)	0.055"（1.40mm）
Current - Power (disabled) (maximum)	25mA

Preview

Download Datasheet

View All

Part Numbering System

EG-2101

CA

250.0000M

Duty Cycle

P

C

H

L0

Packaging

Model Number

P: 45/55 Duty Cycle

Standard for 125.0000MHz ~ 400.0000MHz

D: 47.5 / 52.5 Tight Duty Cycle (see below):

Standard for 62.5~124.999MHz

Optional for 125.00MHz~159.3750MHz

Not available for frequencies over 159.375MHz

Output Frequency

62.5000M ~ 400.0000M

M: Unit in MHz

Power Supply (Vdd),

C: 3.3V type

* Frequency Stability and conditions

Tape and Reel

L0: 1000pcs per reel

L3: 250pcs per reel

Package Type

CA: Ceramic 5x7mm SMD 6-pin

H: +/-100ppm max incl. 0 to +70, loading var, supply voltage var, reflow & 10yrs aging

Y: +/-100ppm incl 0-70C loading, supply voltage var, and reflow

Z: +/-50ppm only 0-70C and calibration. (optional)

PNS_09-02.2
