Accessories
Pins, Terminals and Solder Washers
K36, K24
Inbord Pins for holes- .025”(.6mm) & .042”dia.
K36
K24
• Press-in pins provide excellent solder
points
• Installation tools available separately
• Available in several sizes
• Plating note: Tin plated. Gold plating
available on K24 & K31 styles. Add “A”
suffix to numeric portion of part number.
T42-1
Push-In Terminals for .042” diameter holes
• Wiring terminals for mounting leads
or wires horizontally or vertically
(through board hole)
• Connectors require no staking for
most applications
• Horizontal slot holds up to seven
wires, depending upon thickness of
wire
Swage
Diamond
knurl (K24 only)
Use P133A Insertion Tool
“P” Pattern
Vectorbord
®
T42-1
Micro-Klip
Part No. Pkg Hole A
Qty Size
K24A/M*
K24A/C
K24C/M*
K24C/C
K30C/M
K30C/C
K31C/M
K31C/C
K36C/M
K36C/C
1000
100
1000
100
1000
100
1000
100
1000
100
.042”
.042”
.042”
.042”
.042”
.042”
.042”
.042”
.025”
.025”
.650”
.650”
.650”
.650”
.550”
.550”
.375”
.375”
.705”
.705”
B
.255”
.255”
.255”
.255”
.255”
.255”
.160”
.160”
.293”
.293”
C
.375”
.375”
.375”
.375”
.305”
.305”
.195”
.195”
.400”
.400”
D
.073”
.073”
.073”
.073”
.085”
.085”
.075”
.075”
.040”
.040”
E
.080”
.080”
.080”
.080”
.060”
.060”
.060”
.060”
.050”
.050”
F
.039”
.039”
.039”
.039”
.040”
.040”
.040”
.040”
.023”
.023”
Use P149A (handle type)
or P149 (shank type)
Insertion tool
T28
R32
Push-In Terminals for .062” diameter holes
• Wiring terminals for mounting leads or
wires horizontally or vertically (through
board hole)
• Vertical (longitudinal) slot holes .025”
diameter leads or .22 gauge wires
• Includes .018” diameter tab hole which
accepts transistor wires, can be used
to hold an anchoring wire
Use P91A Insertion tool
*Use in G-10 epoxy glass board only as knurled shoulder may split CEM-1 composite material
Socket Pins for .042” diameter holes
Use P158 Insertion Tool
D9 Die Point
• Low profile wire-wrap socket pins
• Pressfit mounting
• Four-finger contacts, tapered sockets for
easy insertion
• Accepts .015-.025 diameter leads
• Gold-plated contact surfaces
Part No. Pkg A
Qty
R32/C
R32/M
B
C
D
E Male Pin
Depth
.13”
.13”
Part No. Pkg Qty
T28/C
T28/M
100
1000
A
B
100 .745” .500” .072” .155” .075”
1000 .745” .500” .072” .155” .075”
.437” .237”
.437” .237”
R30, R31, R53
Socket Pins for .055” diameter holes
R30
• Low profile,pressfit pins, for hand or dip
solder applications
• Solder post is 0.110” long, extends 0.19”
below and 0.030” above board surface
• Gold-plated contact surfaces
• Low profile wire wrap
• Four-finger contacts, tapered socket for
easy insertion
• Gold-plated contact surfaces
• Two level wire wrap
• Tin-plated contact surfaces
• 3-level wire-wrap pins, .025” sq. posts
• Six-finger contacts, low insertion force sockets
• Gold-plated contact surfaces
T124
Solder Washers - 3 Sizes in Package
Multi-functional solder washer kits, with
three sizes of washers. Different sizes
provided to fit over sockets and tails of
most Vector socket pins and wiring termi-
nals. Ideal tools for committing pins to
voltage and ground planes in Vectorbord
®
patterns, such as Voltage/Ground Plane
and Vectorbord plus
TM
, that have clear-
ance area isolating holes from planes.
R31
R52
R53
T124/M (Includes 3 sizes)
Qty
I.D. O.D. Application
500
500
1000
.078”
.058”
.040”
.110” Vcc Side
.103” GND Side
.106” Connector
Part No. Pkg Qty A
R30/C
R30/M
R31/C
R52/C
R52/M
R53/C
R53/M
100
1000
100
100
1000
100
1000
.110”
.110”
.500”
.370”
.370”
.500”
.500”
B
.286”
.286”
.703”
.570”
.570”
.700”
.700”
C
.072”
.072”
.072”
.072”
.072”
.062”
.062”
D Male Pin Depth
.030”
.030”
-
.031”
.031”
-
-
.15”
.15”
.17
.15-.22”
.15-.22”
-
-
T124-040/500
Qty
I.D. O.D. Application
500
.040”
.106” Connector
