F-219 (Rev 03MAR20)
HLE–130–02–F–DV
HLE–110–02–L–DV
(2.54 mm) .100"
HLE–116–02–L–DV–K
HLE SERIES
COST-EFFECTIVE RELIABLE SOCKET
Mates With:
TSW, MTSW, DW,
EW, ZW, TLW, TSM,
MTLW, HW
HLE
NO.
1
PER PINS
ROW
02
PLATING
OPTION
DV
TAIL
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?HLE
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
BeCu
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (HLE/TSM):
4.1 A per pin
(2 pins powered)
Voltage Rating:
400 VAC
Operating Temp Range:
-55 °C to +125 °C
Insertion Depth:
(1.78 mm) .070" to
(3.43 mm) .135", pass-through,
or (2.59 mm) .102" min
plus board thickness for
bottom entry
RoHS Compliant:
Yes
= Gold flash on contact,
Matte Tin on tail
–F
–L
Leave blank for
Surface Mount
(Requires –BE for
Bottom Entry)
= 10 µ" (0.25 µm) Gold on contact,
Matte Tin on tail
= Through-hole
Top Entry
–TE
= Bottom Entry
(Not available
with –TE)
–BE
–A
= Through-hole
Pass-through Entry
(Requires –BE for
Bottom Entry)
–PE
= Alignment Pin
(4 positions min.)
Metal or plastic at
Samtec discretion
(Not available with
–TE, –PE & –LC)
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max (02-20)
(0.15 mm) .006" max (21-50)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
02 thru 50
= Locking Clip
(2 positions min.)
(Not available
with –A)
(Manual placement
required)
–LC
No. of Positions x (2.54) .100
(2.54)
.100
(2.54)
.100
01
02
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(5.08)
.200
= (6.50 mm) .256"
DIA Polyimide
Film Pick &
Place Pad
(3 positions min.)
Not available
with –TE or
–PE tail option
–K
FILE NO. E111594
ALSO AVAILABLE
(MOQ Required)
• Other platings
(3.66)
.144
(6.60)
.260
(0.51)
.020
(3.51)
.138
= Metal Pick &
Place Pad
(3 positions min.)
(3.05)
.120
–P
–PE
–TE
(7.11) .280
x
(5.71) .225
(2.54)
.100
–TE
= Tape & Reel
Packaging
(29 positions
max.)
–TR
(1.27)
.050
(1.27)
.050
(1.42)
.056
(3.86)
.152
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(1.60)
.063
DIA
–P
–LC
(7.62)
.300
(2.30)
.090
–A
–PE
Due to technical progress, all designs, specifications and components are subject to change without notice.
= Full Reel
Tape & Reel
Packaging
(Must order max.
quantities per reel.
Contact Samtec
for parts per reel)
–FR
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
