Surface Mount Power Inductors
3483-1R0M
3483-1R5M
3483-2R2M
3483-3R3M
3483-4R7M
3483-6R8M
3483-100M
3483-120M
3483-150M
3483-180M
3483-220M
3483-270M
3483-330M
3483-390M
3483-470M
3483-560M
3483-680M
3483-820M
3483-101M
NU
MB
ER
Series 3483 & S3483
SERIES 3483 - UNSHIELDED
1.0
1.5
2.2
3.3
4.7
6.8
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
0.022
0.026
0.032
0.041
0.049
0.067
0.085
0.100
0.130
0.160
0.180
0.240
0.290
0.340
0.410
0.480
0.600
0.710
0.950
2.88
2.67
2.40
2.08
1.92
1.60
1.41
1.28
1.12
1.00
0.93
0.80
0.72
0.66
0.59
0.55
0.49
0.44
0.38
DC
MA RES
XI IST
MU A
M NC
(O E
HM
CU
S)
R
MA RE
XI NT
MU R
M ATI
(A NG
m
ps
)
IN
D
(µ UCT
H) A
±2 NC
0% E
@
10
0K
Hz
POWER INDUCTORS
SERIES 3483 - SHIELDED WITH FERRITE
Physical Parameters
Inches
A
0.276 to 0.299
B
0.114 to 0.138
C
0.276 to 0.299
D
0.067 to 0.091
E
0.201 to 0.224
0.033 Nom.
F
F = Electrode Thickness
Millimeters
7.0 to 7.6
2.9 to 3.5
7.0 to 7.6
1.7 to 2.3
5.1 to 5.7
0.85 Nom.
Current Rating
The DC where inductance value decreases 10% or
where the temperature rise is 40°C Max.
Operating Temperature Range
–20°C to +80°C
Marking
Printed with the last three numbers of the
Delevan Part Number (i.e. 101)
Electrical Characteristics
(Initial) @ 25°C
Notes 1)
Miniature Surface Mount Type
2)
Low Profile
3)
Inductance Range is 1-100µH
4)
Available in Magnetically Shielded or
Unshielded Versions
Packaging
Tape and Reel for Auto Insertion
(16mm): 13" reel, 1000 pieces max.; 7" reel not
available. Quantities less than full reel are on “cut
tape”.
S3483-1R0M
S3483-1R5M
S3483-2R2M
S3483-3R3M
S3483-4R7M
S3483-6R8M
S3483-100M
S3483-120M
S3483-150M
S3483-180M
S3483-220M
S3483-270M
S3483-330M
S3483-390M
S3483-470M
S3483-560M
S3483-680M
S3483-820M
S3483-101M
1.0
1.5
2.2
3.3
4.7
6.8
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
0.019
0.023
0.028
0.035
0.043
0.055
0.080
0.090
0.120
0.130
0.150
0.210
0.250
0.310
0.350
0.430
0.520
0.600
0.790
3.12
2.85
2.66
2.26
1.96
1.76
1.34
1.23
1.09
0.99
0.90
0.81
0.72
0.67
0.60
0.55
0.50
0.46
0.41
www
.
delevan
.
com
E-mail: apisales@delevan.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814
2/ 2002
PAGE
67
