9.6×9.6 Square/ Single Turn /Trimming Potentiometer
-- 3386Y--
...Mutual
dimension............................
...Install
dimension............................
Electrical Characteristics
Standard Resistance Table
Resistance(Ohms)
Resistance Code
Standard Resistance Range................50Ω
½
2MΩ
Resistance Tolerance..................................±10%
Absolute Minimum Resistance..........
≤
1%R
或
10Ω
Contact Resistance Variation.................CRV
≤
3%
Insulation Resistance...............R1
≥
1GΩ
(100Vac)
Withstand Voltage......................................600Vac
Effective Travel.............................................300°
Environmental Characteristics
Power Rating, 315 volts max
........................................0.5W@70℃,0W@125℃
Temperature Range.........................-55℃
½
125℃
Temperature Coefficient....................±250ppm/℃
Temperature Variation............-
55℃,30min,+125℃
.........................................................30min
5cycles
..............................△R
≤
5%R,△(Uab/Uac)
≤
10%
Collision...............100m/s
2
,1000cycles,
△
R
≤
2%R
Electrical Endurance at
70℃...............0.5W@70℃
.................................................1000h,△R
≤
10%R
....................△(Uab/Uac)
≤
10%,CRV
≤
3% or 5Ω
Rotational
Life.........................................200cycles
................................△R
≤
10%R,CRV
≤
3% or 5Ω
10
20
50
100
200
500
1,000
2,000
5,000
10,000
20,000
25,000
50,000
100,000
200,000
250,000
500,000
1,000,000
2,000,000
100
200
500
101
201
501
102
202
502
103
203
253
503
104
204
254
504
105
205
Special resistances available
Physical Characteristics
How To Order
3386----Y--------103
