3329S102 Overview

6.8】4.7 Circularity/ Single Turn /Trimming Potentiometer

Preview

Download Datasheet

View All

6.8×4.7 Circularity/ Single Turn /Trimming Potentiometer

-- 3329S --

...Install

dimension............................

Electrical Characteristics

Standard Resistance Range.................50Ω

2MΩ

Resistance Tolerance...................................±10%

...Mutual

dimension............................

Absolute Minimum Resistance..........

≤

1%R

或

10Ω

Contact Resistance Variation................CRV

≤

Insulation Resistance...............R1

≥

1GΩ

(100Vac)

Withstand Voltage......................................500Vac

Effective Travel...............................................280°

Environmental Characteristics

Power Rating, 300 volts max

......................................0.25W@70℃,0W@125℃

Standard Resistance Table

Resistance(Ohms)

Resistance Code

Temperature Range.........................-55℃

125℃

Temperature Coefficient.....................±250ppm/℃

Temperature Variation...........-55℃,30min,+125℃

........................................................30min 5cycles

...............................△R

≤

5%R,△(Uab/Uac)

≤

Vibration............................10

500Hz,0.75mm,6h

........................△R

≤

5%R,

△(Uab/Uac)

≤

7.5%R

Collision..............390m/s

,4000cycles,

△

≤

5%R

Electrical Endurance at 70℃..............0.5W@70℃

....................1000h,

△R

≤

10%R,CRV

≤

3% or 5Ω

Rotational Life........................................200cycles

...............................△R

≤

10%R,CRV

≤

3% or 5Ω

How To Order

3329-----S-------103

100

200

500

1,000

2,000

5,000

10,000

20,000

25,000

50,000

100,000

200,000

250,000

500,000

1,000,000

2,000,000

100

200

500

101

201

501

102

202

502

103

203

253

503

104

204

254

504

105

205

Special resistances available
