3266Z202 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > 3266Z202

Preview

3266Z202: Description7.2】6.7 Square/Multiturn/Trimming Potentiometer; File Size168KB，1 Pages; ManufacturerDBLECTRO; Websitehttp://www.dblectro.com

Download Datasheet View All

3266Z202 Overview

7.2】6.7 Square/Multiturn/Trimming Potentiometer

Preview

Download Datasheet

View All

7.2×6.7 Square/Multiturn/Trimming Potentiometer

-- 3266Z--

..Common

Dimensions...........................

Standard Resistance Table

Electrical Characteristics

Standard Resistance Range..................50Ω

2MΩ

Resistance Tolerance....................................±10%

Absolute Minimum Resistance...........

≤

1%R

或

10Ω

Contact Resistance Variation.........CRV

≤

或

5Ω

Insulation Resistance................R1

≥

1GΩ(100Vac)

Withstand Voltage.......................................500Vac

Effective Travel...................................12 turns nom

Environmental Characteristics

Power Rating,315 volts max

......................... .............0.25W@70℃,0W@125℃

Temperature Range..........................-55℃

125℃

Temperature Coefficient.......................±250ppm/℃

Temperature Variation.............-55℃,30min,+125℃

.........................................................30min 5cycles

................................△R

≤

5%R,△(Uab/Uac)

≤

Vibration..............................10

500Hz,0.75mm,6h,

..........................△R

≤

5%R,

△(Uab/Uac)

≤

7.5%R

Collision...................................390m/s

,4000cycles

.............................................................△R

≤

5%R

Electrical Endurance at 70℃

Resistance(Ohms)

100

200

500

1,000

2,000

5,000

10,000

20,000

25,000

50,000

100,000

200,000

250,000

500,000

1,000,000

2,000,000

Resistance Code

100

200

500

101

201

501

102

202

502

103

203

253

503

104

204

254

504

105

205

Special resistances available

How To Order

3266----Z--------103

...............................................0.25W@70℃ 1000h,

.............△R

≤

10%R,R1

≥

100MΩ,CRV

≤

3% or 5Ω

Rotational Life...........................................200cycles

..................................△R

≤

10%R,CRV

≤

3% or 5Ω

Physical Characteristics

Starting Torque.........................................

≤

35mN·m

Marking..............when no identification, it is of±10%
