F-209
ZSS–110–03–S–D–0715
HTSS–117–01–S–DV
SHROUDED HEADER
TSS, HTSS, ZSS
Mates with:
SSW, SSQ, ESW, ESQ,
SSM, BCS
TST, HTST, ZST
Mates with:
IDSD
TSS, TST, HTSS, HTST,
ZSS, ZST SERIES
PLATING
OPTION
TAIL
OPTION
BODY
HEIGHT
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
SPECIFICATIONS
For complete specifications
see www.samtec.com?TSS,
www.samtec.com?TST,
www.samtec.com?HTSS,
www.samtec.com?HTST,
www.samtec.com?ZSS or
www.samtec.com?ZST
Insulator Material:
Black Glass
Filled Polyester
(TSS, TST, ZSS, ZST)
Natural PCT (HTSS, HTST)
Insulation Resistance:
5000 MΩ min
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
3A
Operating Temp Range:
-55°C to +125°C with Gold
-55°C to +105°C with Tin
Flamability Rating:
UL 94V-O
Withstanding Voltage:
1000 VRMS
RoHS Compliant:
Yes
TSS
= Top Shrouded
Connector Strip
Specify “LEAD STYLE”
from chart
HTSS/HTST
TSS/TST
STRAIGHT
LEAD STRAIGHT
STYLE TAIL LENGTH TAIL LENGTH
(A)
(A)
–D
= Double Row Through-hole
(Lead style –01, –02 & –03 only or
BODY HEIGHT must be specified)
TST
= Top Shrouded
Cable Strip
HTSS
= High Temp
Top Shrouded
Connector Strip
–01
–02
–03
(2,92) .115
(4,19).165
(14,35) .565
(3,30) .130
(4,57) .180
(14,73) .580
(2,54)
.100
(6,35)
.250
A
(2,54)
.100
–DV
= Double Row Surface Mount
(Lead style –01 only)
(HTSS, HTST only)
–D
B
(5,08)
.020
–D–RA
= Double Row Right Angle
(Lead style –04 & –05 only)
(ZSS, ZST N/A)
HTST
= High Temp
Top Shrouded
Cable Strip
ZSS/ZST
LEAD OVERALL
STYLE LENGTH
(C)
(2,54) .100
–D–RA
TSS/TST/
HTSS/HTST
LEAD RIGHT ANGLE
STYLE TAIL LENGTH
(B)
ZSS
= Elevated
Connector Strip
–“XXXX”
= Body Height
(ZSS, ZST & –D only)
LEAD MAX. BODY
HEIGHT
STYLE
ZST
= Elevated
Cable Strip
Processing:
Max Processing Temp:
HTSS & HTST only:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead–Free Solderable:
Yes (HTSS, HTST)
Wave Only (TSS, TST,
ZSS, ZST)
SMT Lead Coplanarity:
(0,15mm) .006"
–01
–02
–03
–04
–05
–06
–07
–08
–09
(16,00) .630
(18,54) .730
(21,08) .830
(23,62) .930
(26,16) 1.030
(28,70) 1.130
(31,24) 1.230
(33,78) 1.330
(36,32) 1.430
–04
–05
(3,30) .130
(5,84) .230
(6,35)
.250
Body
Height
HTSS/HTST
Lead Style –01
(10,16)
.400
(11,18)
.440
(6,35)
.250
(2,54)
.100
(2,29)
.090
MIN
–DV
–01
–02
–03
–04
–05
–06
–07
–08
–09
.540 (13,72)
.640 (16,26)
.740 (18,80)
.840 (21,34)
.940 (23,88)
1.040 (26,42)
1.140 (28,96)
1.240 (31,50)
1.340 (34,04)
For board stacking height add .085" (2,16mm)
when mated with SSW series.
05, 07, 08, 10, 12, 13, 15, 17, 20, 25, 32, 36
(Call Samtec for other sizes.)
Y
(2,54)
.100
(0,38)
.015
Example: ZST-1XX-01-X-X-465 mated with
SSW = (13,97mm) .550" board space
APPLICATION
SPECIFIC OPTION
• Alignment Pins
• Single Row
• Locking Leads
• Polarized
Call Samtec.
X
02
–G
= 10µ" (0,25µm) Gold on contact area,
Gold flash on balance
(Not available on -DV)
(6,35) (8,89)
.250 .350
01
(5,1)
.20
TYPE
STRIP
(8,89)
.350
X
Y
–S
= 30µ" (0,76µm) Gold on contact area,
Matte Tin on tail
(0,38)
.015
(0,64) .025 SQ TYP
HTSS
TSS
ZSS
HTST
TST
ZST
Note:
Some lengths, styles
and options are non-standard,
non-returnable. ZSS, ZST are
non-standard, non-returnable.
TSS , TST
ZSS, ZST
(2,54) .100 (2,54) .100
X No. of
X No. of
Positions
Positions
+ (1,27) .050 + (3,81).150
(2,54).100
(2,54).100
X No. of
X No. of
Positions
Positions
+ (5,08).200 + (7,62) .300
–L
= 10µ" (0,25µm) Gold on contact area,
Matte Tin on tail
–T
= Matte Tin
