INTERCONNECTS
SERIES 451 • .100” GRID INTERCONNECT HEADERS •
DOUBLE ROW STRIPS
•
Series 451 interconnect header strips come in
.100
.025 DIA.
OR .018 DIA.
.072 DIA.
.063 DIA.
.252
.110
.134
three lengths with .018” dia. pluggable solder
tails at one end and .025” dia. pins at the other.
Please see series:
451...003 uses pin #5503
451...004 uses pin #5504
451...005 uses pin #5505
both ends. Please see series:
451...009 uses pin #5509
451...010 uses pin #5510
451...011 uses pin #5511
See pages 212 and 214 for details
•
.018” pluggable solder tails are available at
.126
.031
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
.154
.018 DIA.
ORDERING INFORMATION
Series 451...003
Specify number of pins
FIG. 1
.100
.025 DIA.
OR .018 DIA.
.126
.047 DIA.
.018” / .025” Dia. Solder Tails
451 10 2_ _ 00 003000
04-64
FIG. 1
Series 451...009
Specify number of pins
.018” / .018” Dia. Solder Tails
451 10 2_ _ 00 009000
04-64
.072 DIA.
.110
.331
.136
Series 451...004
Specify number of pins
.018” / .025” Dia. Solder Tails
451 10 2_ _ 00 004000
04-64
.018 DIA.
.154
FIG. 2
Series 451...010
Specify number of pins
.018” / .018” Dia. Solder Tails
451 10 2_ _ 00 010000
04-64
FIG. 2
.100
.025 DIA.
OR .018 DIA.
.126
.047 DIA.
Series 451...005
Specify number of pins
.018” / .025” Dia. Solder Tails
451 10 2_ _ 00 005000
04-64
PAGE 80 | INTERCONNECTS
FIG. 3
.606
.110
.136
Series 451...011
Specify number of pins
.018” / .018” Dia. Solder Tails
451 10 2_ _ 00 011000
04-64
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.072 DIA.
.018 DIA.
.154
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
10
10
µ”
Au
FIG. 3
SPECIFY PLATING CODE XX=
Pin Plating
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
