CLD-DS159 Rev 3B
Product family data sheet
Cree
®
XLamp
®
CMA1516 LED
ProDuCt DEsCriPtion
Cree’s XLamp
®
High-Current LeD Array
family is optimized for best-in-class
lumen output, efficacy and reliability at
high drive currents. XLamp CMA LeDs
share the same package design and
LeS sizes as Cree’s industry-leading
CXA2 Standard Density LeDs, enabling
lighting manufacturers to address a
range of performance requirements for
applications such as track, downlight
and outdoor lighting using
High-Current
LeD
Arrays
are
now
FEAturEs
•
•
9-mm optical source
Mechanical and optical design
consistent with CXA15 and CXB15
LeDs
•
•
•
Cree easyWhite
®
2-, 3- and 5-step
binning
Premium Color 2- and 3-step binning
Standard & Premium Color LeDs
available in 70, 80, 90 and 95 CRI
minimum options
•
•
•
•
•
eTone™ LeDs available in 90 CRI
minimum option
Forward voltage option: 36-v class
85 °C binning and characterization
Maximum drive current: 1050 mA
115° viewing angle, uniform
chromaticity profile
•
•
•
Top-side solder connections
RoHS and ReACh compliant
UL
®
recognized component
(e349212)
tAbLE oF ContEnts
Characteristics ............................................2
Operating Limits ..........................................3
Flux Characteristics, Order Codes & Bins -
Standard LeDs .............................................4
Flux Characteristics, Order Codes & Bins -
Standard LeDs, Premium Color ..................5
Flux Characteristics, Order Codes and
Bins - eTone™ LeDs .....................................6
Relative Spectral Power Distribution -
Standard LeDs .............................................7
Relative Spectral Power Distribution -
Standard LeDs, Premium Color ..................8
Relative Spectral Power Distribution -
eTone™ LeDs ............................................ 10
electrical Characteristics ......................... 10
Relative Luminous Flux ............................ 11
Typical Spatial Distribution...................... 11
easyWhite
®
Performance Groups -
Chromaticity ............................................. 12
Premium Color Performance Groups -
Chromaticity ............................................. 13
Cree easyWhite
®
Bins Plotted on the
1931 CIe Color Space .............................. 14
Cree Premium Color Bins Plotted on the
1931 CIe Color Space .............................. 15
Bin and Order Code Formats ................... 17
Mechanical Dimensions .......................... 18
Thermal Design ........................................ 19
Notes ........................................................ 20
Packaging ................................................. 21
available in two different versions:
Standard and eTone LeDs.
The eTone version delivers beautiful 90
CRI light quality at the same efficacy
as today’s standard 80 CRI LeDs.
Featuring the same mechanical and
optical characteristics as the Standard
version, the eTone LeDs allow easy
upgrades from 80 CRI to 90 CRI without
sacrificing performance.
WWW.CREE.Com/XLAmp
Copyright © 2017-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo,
XLamp
®
and EasyWhite
®
are registered trademarks and eTone™ is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
Cma1516 LED
oPErAting LiMits
The maximum current rating of the CMA1516 depends on the case temperature (Tc) when the LeD has reached thermal equilibrium
under steady-state operation. The graph shown below assumes that the system design employs good thermal management (thermal
interface material and heat sink) and may vary when poor thermal management is employed. either solder pad shown in the Mechanical
Dimensions section on page 18 can be used as the Tc measurement point.
Another important factor in good thermal management is the temperature of the Light emitting Surface (LeS). Cree recommends a
maximum LES temperature of 140 °C to ensure optimal LED lifetime. Please refer to the Thermal Design section on page 19 for more
information on LeS temperature
V
CMA1516 - 36
measurement.
1100
1000
900
800
700
85 °C, 1050 mA
Standard LEDs
If (mA)
600
500
400
300
200
100
0
125 °C, 404 mA
CMA1516 e Tone
900
800
700
600
0
25
50
75
100
125
150
Case Temperature (°C)
85 °C, 840 mA
eTone LEDs
If (mA)
500
400
300
200
100
0
0
25
50
75
100
125
150
Case Temperature (°C)
Copyright © 2017-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo, XLamp
®
and EasyWhite
®
are registered trademarks and
eTone™ is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
Cma1516 LED
FLuX ChArACtEristiCs, orDEr CoDEs & bins - stAnDArD LEDs (i
F
= 450 mA,
t
J
= 85 °C)
The following table provides order codes for XLamp CMA1516 LeDs. For a complete description of the order code nomenclature, please
see the Bin and Order Code Formats section (page 17).
nominal
CCt
Cri
Min.
70
6500 K
80
70
5700 K
80
90
70
5000 K
80
90
70
4000 K
80
90
80
3500 K
90
70
3000 K
80
90
80
2700 K
90
2200 K
80
92
82
1614
1691
1736
1818
27H
92
73
82
92
82
1767
2111
2000
1691
1919
1900
2270
2150
1818
2063
30H
30H
27H
CMA1516-0000-
000N0H0A30H
CMA1516-0000-
000N0U0A30H
CMA1516-0000-
000N0H0A27H
CMA1516-0000-
000N0U0A27H
30G
30G
27G
27G
22G
CMA1516-0000-
000N0H0A30G
CMA1516-0000-
000N0U0A30G
CMA1516-0000-
000N0H0A27G
CMA1516-0000-
000N0U0A27G
CMA1516-0000-
000N0H0A22G
35H
82
73
82
92
73
82
92
73
82
92
82
2155
2354
2199
1870
2285
2135
1870
2268
2111
1817
2059
2317
2531
2364
2011
2457
2296
2011
2439
2270
1954
2214
40H
40H
35H
CMA1516-0000-
000N0H0A40H
CMA1516-0000-
000N0U0A40H
CMA1516-0000-
000N0H0A35H
CMA1516-0000-
000N0U0A35H
40G
40G
35G
35G
CMA1516-0000-
000N0H0A40G
CMA1516-0000-
000N0U0A40G
CMA1516-0000-
000N0H0A35G
CMA1516-0000-
000N0U0A35G
30e
CMA1516-0000-
000N0B0A30e
50G
50G
CMA1516-0000-
000N0H0A50G
CMA1516-0000-
000N0U0A50G
40e
CMA1516-0000-
000N0B0A40e
57G
CMA1516-0000-
000N0U0A57G
50e
CMA1516-0000-
000N0B0A50e
65e
57e
57e
typ
73
Minimum
Luminous
Flux (lm)
2306
typical
Luminous
Flux (lm)
2480
2-step
group
order Code
group
3-step
order Code
group
65e
5-step
order Code
CMA1516-0000-
000N0B0A65e
CMA1516-0000-
000N0H0A65e
CMA1516-0000-
000N0B0A57e
CMA1516-0000-
000N0H0A57e
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a tolerance of ±2 on CRI
measurements. See the Measurements section (page 20).
•
For 80 CRI minimum LeDs, CRI R9 minimum is 0 with a ±2 tolerance. For 90 CRI minimum LeDs, CRI R9 typical is 60.
Copyright © 2017-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo, XLamp
®
and EasyWhite
®
are registered trademarks and
eTone™ is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
Cma1516 LED
FLuX ChArACtEristiCs, orDEr CoDEs & bins - stAnDArD LEDs, PrEMiuM CoLor (i
F
= 450 mA,
t
J
= 85 °C)
Fidelity
nominal
CCt
4000 K
3500 K
3000 K
2700 K
Cri
Min.
95
95
95
95
typ
98
98
98
98
Minimum
Luminous
Flux (lm)
1628
1584
1481
1402
typical
Luminous
Flux (lm)
1750
1703
1593
1508
2-step
group
L5A
35H
30H
27H
order Code
CMA1516-0000-000N0Z0AL5A
CMA1516-0000-000N0Z0A35H
CMA1516-0000-000N0Z0A30H
CMA1516-0000-000N0Z0A27H
specialty
nominal
CCt
3100 K
Cri
Min.
90
80
3000 K
90
95
typ
92
82
92
98
Minimum
Luminous
Flux (lm)
1691
2000
1691
1481
typical
Luminous
Flux (lm)
1818
2150
1818
1593
L7C
CMA1516-0000-
000N0Z0AL7C
L7B
CMA1516-0000-
000N0H0AL7B
30Q
CMA1516-0000-
000N0U0A30Q
30U
CMA1516-0000-
000N0U0A30U
2-step
group
order Code
group
31Q
order Code
CMA1516-0000-
000N0U0A31Q
3-step
group
order Code
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a tolerance of ±2 on CRI
measurements. See the Measurements section (page 20).
•
For 80 CRI minimum LeDs, CRI R9 minimum is 0 with a ±2 tolerance. For 90 CRI minimum LeDs, CRI R9 typical is 60.
Copyright © 2017-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo, XLamp
®
and EasyWhite
®
are registered trademarks and
eTone™ is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
