DS3696N/NOPB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Drivers and interfaces> DS3696N/NOPB

DS3696N/NOPB: DescriptionLINE TRANSCEIVER, PDIP8; CategoryDrivers and interfaces; File Size734KB，2 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric View All

DS3696N/NOPB Overview

LINE TRANSCEIVER, PDIP8

DS3696N/NOPB Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
package instruction	DIP,
Reach Compliance Code	unknown
Is Samacsys	N
Other features	COMMON I/O; 1 RECEIVER ACTIVE UNDER SHUTDOWN; FAULT FLAG
Differential output	YES
Number of drives	1
Input properties	DIFFERENTIAL SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-422; EIA-485
JESD-30 code	R-PDIP-T8
JESD-609 code	e3
length	9.817 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	260
Certification status	COMMERCIAL
Maximum receive delay	37 ns
Number of receiver bits	1
Maximum seat height	5.08 mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal surface	TIN
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
maximum transmission delay	22 ns
width	7.62 mm
Base Number Matches	1
