Product Specification
Material
Insulator : Glass-Filled Thermoplastic PBT,UL94V-0,White
Contact : Copper alloy, Gold flash selective gold
6
Shell: Steel 100u''Tin Over 50u'' min Copper
B
Electrical
Contact Resistance : 20 milliohms Max at 1 AMP DC.
Insulation Resistance : 1000 magohms at 500 VDC
Dielectric Withstanding Voltage : 1000 VAC/rms 60Hz for 1 minute
Current Rating : 3 AMP
Volatge Rating : 250 VAC/rms 60Hz
5
Durability :250 mating cycles
1
7
B
C
C
2
D
Order Code:
A-Dx xx LL/Z
Contact style:
F - Female
S - Male
LL/Z - Selective gold*
No. of Contacts
09 / 15 / 25 / 37
D
2
E
Dimensions
Positions
9
15
25
37
A
30.81
39.20
53.04
69.40
B
24.99
33.30
47.04
63.50
C
16.92
25.25
38.96
55.42
E
11.08
19.39
33.24
49.86
F
19.20
27.70
41.10
57.30
E
F
50 Positions
2
F
Scale
Free
7 Add solder temperature
6 Add the detail plating of shell
5 Add the mating cycles
4 Cancel "Clinch Nut "&"Screwlock"
16.07.2018
17.01.2018
19.10.2017
17.06.2016
03.04.2015
27.02.2015
Date
Xavier
Tom
Winnie
Winnie
Drawing-No.
3 Add the UL number
2 Update the dimension
Winnie
Winnie
Replace
Name
Sheet
1/2
Drawn
Approved
Date
15.08.2012
16.07.2018
Name
Lucas
Winnie
ASSMANN WSW-No.
Customer-No.
TOLERANCE
G
3
RoHS compliant
Unit: mm
File No.: E198287
X.
X.X
X.XX
DIM
TOL
G
A-Dx xx LL/Z
ASS 4884 CO
rev07
H
Angle
TOL
H
Id.
Modification
1
2
3
4
5
6
7
1
Female
A
2
3
4
5
6
7
A
B
Product Specification
Material
Insulator : Glass-Filled Thermoplastic PBT,UL94V-0,White
Contact : Copper Alloy , Gold flash selective gold plating
6
Shell: Steel 100u''Tin Over 50u'' min Copper
B
C
2
Electrical
Contact Resistance : 20 milliohms Max at 1 AMP DC.
Insulation Resistance : 1000 magohms at 500 VDC
Dielectric Withstanding Voltage :1000 VAC/rms 60Hz for 1 minute
Current Rating : 3 AMP
Volatge Rating : 250 VAC/rms 60Hz
5
Durability :250 mating cycles
1
7
C
D
Dimensions
Positions
9
15
25
37
A
30.81
39.20
53.05
69.40
B
24.99
33.30
47.04
63.50
D
16.33
24.70
38.40
54.84
E
11.08
19.39
33.24
49.86
F
19.20
27.70
41.10
57.30
D
E
E
F
50 Positions
Scale
Free
TOLERANCE
2
2
F
16.07.2018
17.01.2018
19.10.2017
17.06.2016
03.04.2015
27.02.2015
Date
Xavier
Tom
Winnie
Winnie
Drawing-No.
Winnie
Winnie
Replace
Name
Sheet
2/2
Drawn
Approved
Date
15.08.2012
16.07.2018
Name
Lucas
Winnie
ASSMANN WSW-No.
Customer-No.
7 Add solder temperature
6 Add the detail plating of shell
5 Add the mating cycles
4 Cancel "Clinch Nut "&"Screwlock"
G
3
RoHS compliant
Unit:mm
File No.: E198287
X.
X.X
X.XX
DIM
TOL
G
A-Dx xx LL/Z
ASS 4884 CO
rev07
3 Add the UL number
2 Update the dimension
H
Angle
TOL
H
Id.
Modification
1
2
3
4
5
6
7
