PRODUCT BRIEF
Key Features
Analog Carrier Loading from
50 MHz to 3000 MHz
Wavelengths can tuned across
the entire C-band at 100 GHz
ITU DWDM spacings
Tunes to different wavelength
in less than 0.5 seconds
Packaged in standard XFP
pluggable optical module
Built-in digital diagnostic
functions
Link distance up to 15
kilometers
LC/APC optical connection
Power consumption less than
3.5 Watts
Operating temperature range of
0°C to 65°C
Compliant with SCTE 195 2013:
Interface Specifications for an
RF-Modulated Small Form Factor
Pluggable Optical Module
Mechanical dimensions
compliant with 10 Gigabit Small
Form Factor Pluggable Module
(XFP) Multi-Source Agreement
(INF-8077i, Rev. 4.5)
50 MHz to 3000 MHz
Pluggable XFP-RF Transmitter
Wavelength tunable, 3 GHz pluggable
optical transmitter module
Overview
Finisar’s XFP-RF transmitter is a small form factor hot-pluggable optical module
that is compliant with interface specifications developed by the Society of Cable
Telecommunications Engineers (SCTE). It can be fully loaded with analog carriers from
50 MHz to 3000 MHz in order to enable operators to effectively utilize a broad range of
frequencies when designing distributed antenna systems and RF Over Fiber networks.
The small XFP module significantly reduces power consumption and increases density for
downstream transmitters.
The transmitter wavelength can be tuned to any of the 43 different Dense Wavelength
Division Multiplexing (DWDM) wavelengths across the entire C-band in less than 500
ms. This increases operational efficiencies in deploying DWDM networks and reduces
inventory of transmitters at different fixed wavelengths. Wavelength tunability also opens
the possibility of novel HFC architectures that can dynamically route services and increase
bandwidth capacity in the cable operator’s access network.
Key Advantages
2x to 4x density improvement over current transmitter solutions
At least 50% less power consumption per transmitter
Enables future HFC architectures to route services dynamically by changing the
wavelength of the transmitter
Enables pluggable optics to be utilized directly in next-generation Cable Modem
Termination Systems and QAM modulators
Applications
Antenna Remoting
Distributed Antenna Systems
(DAS) to Extend Wireless
Infrastructure
1550nm Broadcast with DWDM
Narrowcast Overlay architectures
All-Digital QAM networks
50 MHz to 3000 MHz Pluggable XFP-RF HFC Transmitter
Specifications
Parameter
Optical Output Power
Optical Wavelengths
Center Wavelength Spacing
Wavelength Tuning Time
Optical Connection
Optical Fiber Distance
Fiber Dispersion Compensation, Internal
or External
SBS Suppression
RF Bandwidth
Link Gain*
Noise Figure*
SFDR (3rds)*
IIP3*
RF Input Level
RF Impedance
RF Flatness
RF Input Return Loss
Dimensions
Mounting
Operating Temperature Range
Storage Temperature Range
Power Consumption
Data/Control
4 dBm minimum
ITU DWDM Channels 18 to 60 (1528.77 nm to 1529.55 nm)
100 GHz
0.5 seconds maximum
LC/APC receptacle
0 km to 15 km
Not applicable
+12 typical, with optical amplifier
50 MHz to 3000 MHz
>0dB, 50 MHz to 3000 MHz
<28dB, 50 MHz to 2200 MHz; <30 dB, 2200 MHz to 3000 MHz
>108 dB/Hz, 50 MHz to 2200 MHz
>103 dB/Hz, 2200 MHz to 3000 MHz
>8 db, 50 MHz to 2200 MHz
>6 dB, 2200 MHz to 3000 MHz
Dependent on host module (-20 dBm composite into XFP-RF)
Dependent on host module (100 Ω differential or 50 Ω single-ended into XFP-RF)
2.0 dB max, peak to peak, 50 MHz to 3000 MHz
10 dB min, 50 MHz to 3000 MHz
78 mm (L ) X 18.35 mm (W) X 8.5 mm (H)
3.0 in (L) X 0.7 in (W) X 0.3 in (H)
XFP cage assembly on host module
0˚C to 65˚C
-40˚C to 85˚C
3.5 Watts maximum
Digital diagnostic functions via two-wire serial interface
Value
* With Finisar Optical Receiver. 1 km of SMF-28 single-mode fiber. Host system or chassis may degrade performance.
Product Selection
Part Number
XT04AARTENJD1860
XT04AAR5ENJDxxx
Description
XFP-RF Pluggable Tx, Wavelength-Tunable, 50 MHz to 3000 MHz, +4 dBm
XFP-RF Pluggable Tx, Fixed Wavelength, 50 MHz to 3000 MHz, +4 dBm
xxx – fixed wavelength designated with ITU DWDM channel number
