Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 891816
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
1 X 1 HOOKUP
18 (16/30) AWG TC
0.016" Wall, Nom. PVC
0.047
0.079+/- 0.002
(1) Print
18 AWG EXXXXX RU AWM STYLE 1569 105C 300V VW-1 OR
AWM 1007 LLXXXXX CSA AWM I A/B 105C 300V FT1
OR TR-64 90C
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
BLACK, BROWN, RED, ORANGE, YELLOW, GREEN, BLUE
VIOLET, GRAY, WHITE, LT. BLUE
(2) Color(s)
Applicable Specifications
1) UL
AWM/STYLE 1569
AWM/STYLE 1007
VW-1
2) CSA International
AWM I A/B
FT1
TR-64
90°C
105°C / 300 VRMS
105°C / 300 VRMS
80°C / 300 VRMS
Environmental
1) EU Directive 2002/95/EC(RoHS):
All materials used in the manufacture of this part are in compliance with EU Directive
2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and
electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.
Properties
Physical & Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
Electrical Properties
1) Voltage Rating
2) Inductance
3) Conductor DCR
-20 to 105°C
10X Cable Diameter
12.6 Lbs, Maximum
(For Engineering purposes only)
300 VRMS
0.05 µH/ft, Nominal
7.1 /1000ft @20°C, Nominal
Other
Packaging
a) 5000 FT
b) 1000 FT
c) 500 FT
d) 100 FT
e) Bulk(Made-to-order)
[Spool dimensions may vary slightly]
Flange x Traverse x Barrel (inches)
12 x 6 x 3.5 Continuous length
6.5 x 4 x 2.5 Continuous length
6.5 x 2 x 1.9 Continuous length
3.5 x 3 x 1.125 Continuous length
www.alphawire.com
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742)
Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure there accuracy at the time of publication, information and specifications
described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not
ensure product availability.
Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or
implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,
even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out
of or in connection with the use, or inability to use, the information or specifications described herein.
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
RoHS CERTIFICATE OF COMPLIANCE
To Whom It May Concern:
Alpha Wire Part Number:891816
891816 , RoHS-Compliant Commencing With7/1/2005Production
This document certifies that the Alpha part numbers cited above are manufactured in accordancewith Directive 2002/95/EC of the European
Parliament and of the Council of 27 January 2003,better known as the RoHS Directives, with regards to restrictions of the use of certain
hazardoussubstances used in the manufacture of electrical and electronic equipment. The reader is referredto these Directives for the specific
definitions and extents of these Directives.
No Exemptions arerequired for RoHS Compliance on this item.
Substance
Lead
Mercury
Cadmium
Hexavalent Chromium
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
Including Deca-BDE
Maximum Control Value
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
0.01% by weight (100 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
The information provided in this document and disclosure is correct to the best of Alpha Wire'sknowledge, information and belief at the date of its
release. The information provided is designedonly as a general guide for the safe handling, storage, and any other operation of the productitself or
