F-218 (Rev 18MAY18)
T1M–05–F–SH–L
T1M–07–F–SV–L
ISS1–10–L
CC09R–01–GF
(1.00 mm) .0394"
ISS1, CC09R, CC09M, T1M SERIES
DISCRETE WIRE COMPONENTS & TOOLING
SPECIFICATIONS
For complete specifications
see www.samtec.com?ISS1,
www.samtec.com?CC09R or
www.samtec.com?CC09M
TYPE
NO. OF POSITIONS
LATCH
TYPE
01
PLATING
TOOLING
• Hand tool:
CAT-HT-309-2830-12
• Clamp for mounting
hand tool to work table:
CAT-HT-MNT-01
• Mini Applicator:
CAT-MA-309-2830-XX-01
= Single Row
Body
No. of positions
x (1.00) .03937
+ (1.20) .047
ISS1
–02, –03, –05,
–07, –10, –15, –20
No. of
positions x
(1.00) .03937
+ (3.00) .118
(Leave blank
for no latch)
= Positive
Latch
–L
= Contact, Full Reel
(25,000 Parts per Reel)
CC09R
= 3 µ" (0.07 µm)
Gold contact
and tail
–GF
–T
= Contact, Mini Reel
(1,000 Parts per Reel)
CC09M
= Tin
(1.00) .03937
No. of
positions x
(1.00) .03937
+ (3.00) .118
(3.60)
.141
(2.10)
.083
(9.01)
.355
(2.76)
.109
(3.60)
.141
No. of positions
x (1.00) .03937
+ (3.00) .118
(4.20)
.165
(1.00)
.03937
(3.81)
.150
LATCH
(5.00)
.197
NO LATCH
Insulator Material:
Natural Nylon
Contact Material:
Phosphor Bronze
Mates with:
S1SS(T)
T1M
SPECIFICATIONS
For complete specifications
see www.samtec.com?T1M
Insulator Material:
Natural LCP
Terminal Material:
Phosphor Bronze
Weld Tab:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range
(S1SS(T)/T1M):
-10 °C to +85 °C (PVC)
-40 °C to +125 °C (Teflon
®
cable with -GF plated contact)
Current Rating
(S1SS (28 AWG)/T1M):
3.3 A per pin (1 pin powered)
Voltage Rating:
250 VAC/353 VDC
RoHS Compliant:
Yes
NO. OF
POSITIONS
PLATING
OPTION
ROW
OPTION
LATCH
OPTION
–02, –03, –05, –07,
–10, –15, –20
= 3 µ" (0.07 µm)
Gold on contact,
Matte Tin on tail
–F
–T
= Single Row
Horizontal
= Single Row
Vertical
–SH
–SV
(Required in
callout)
= Positive Latch
–L
= (4.00 mm) .157" DIA
Polyimide Film Pick
& Place Pad
(–SH only)
–K
= Tin
= Pick & Place Pad
(–SV only)
–P
(0.20)
.008
(4.25)
.167
(5.20)
.205
No. of positions
x (1.00) .0394
+ (2.40) .094
(4.25)
.167
(1.00)
.0394
OTHER
SOLUTIONS
• Without latch
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
No. of positions
x (1.00) .0394
+ (2.40) .094
(4.60)
.181
(1.00)
.0394
(1.50)
.059
(5.10)
.201
(5.50)
.217
(4.45)
.179
(0.20)
.008
(0.80)
.031
(1.50)
.059
(3.90)
.154
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
–SH
Due to technical progress, all designs, specifications and components are subject to change without notice.
–SV
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
