BSS314PEL6327HTSA1 datasheet, PDF

Datasheet> All Categories > semiconductor> Discrete semiconductor> BSS314PEL6327HTSA1

BSS314PEL6327HTSA1: DescriptionMOSFET P-CH 30V 1.5A SOT23; Categorysemiconductor Discrete semiconductor; File Size486KB，9 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/; Environmental Compliance

Download Datasheet Parametric View All

BSS314PEL6327HTSA1 Overview

MOSFET P-CH 30V 1.5A SOT23

BSS314PEL6327HTSA1 Parametric

Parameter Name	Attribute value
FET type	P channel
technology	MOSFET (metal oxide)
Drain-source voltage (Vdss)	30V
Current - Continuous Drain (Id) at 25°C	1.5A（Ta）
Drive voltage (maximum Rds On, minimum Rds On)	4.5V，10V
Rds On (maximum value) when different Id, Vgs	140 milliohms @ 1.5A, 10V
Vgs (th) (maximum value) when different Id	2V @ 6.3µA
Gate charge (Qg) at different Vgs (maximum value)	2.9nC @ 10V
Vgs (maximum value)	±20V
Input capacitance (Ciss) at different Vds (maximum value)	294pF @ 15V
FET function	-
Power dissipation (maximum)	500mW（Ta）
Operating temperature	-55°C ~ 150°C（TJ）
Installation type	surface mount
Supplier device packaging	PG-SOT23-3
Package/casing	TO-236-3，SC-59，SOT-23-3

Preview

Download Datasheet

View All
