MC-156 32.7680KA-A0:ROHS Overview

CRYSTAL 32.7680KHZ 12.5PF SMD

MC-156 32.7680KA-A0:ROHS Parametric

Parameter NameAttribute value
typekHz crystal (tuning fork)
frequency32.768kHz
frequency stability-
frequency tolerance±20ppm
load capacitance12.5pF
ESR (equivalent series resistance)65 kOhms
Operating modebasic harmony
Operating temperature-40°C ~ 85°C
grade-
Installation typesurface mount
Package/casing4-SOJ, 5.08mm pitch
size/dimensions0.280" long x 0.098" wide (7.10mm x 2.50mm)
Height - Installation (maximum)0.059"(1.50mm)
Product Configuration System
kHz Range Crystals Units
MC‐156
32.7680K
A
A
5
:
PURE SN
Frequency
32.7680kHz
K:  In kHz
Frequency Tolerance@25C
A:  +/‐20ppm  (Standard)
Load Capacitance
A:  12.5pf
AC:  9pf
AG:  7.0pf
Packaging
Tape & Reel Qty
Blank:  Bulk
3:  250pcs/reel
0:  1000pcs/reel
5:  3000pcs/reel
PURE SN
ROHS
Blank = Not RoHs Compliant
32.7680kHz Crystal Package Type:
MC‐146:  4pin “J” lead SMD, 1.4mm Height
MC‐156:  4pin “J” lead SMD, 1.5mm Height
MC‐206*:  4pin SOP, 2.0mm Height
MC‐206:
Not Recommended for New Designs
NOTES:
1)
This product configuration guide is applicable only to 32.7680kHz
Crystals.  For other frequencies, please reference the Standard kHz
Crystal Product Configuration System.
If you require a load capacitance other than the above listed, please
contact your EEA representative for assistance.
2)
