MA-306 18.4320M-C0:ROHS datasheet, PDF

Datasheet> All Categories > Passive components> MA-306 18.4320M-C0:ROHS

MA-306 18.4320M-C0:ROHS: DescriptionCRYSTAL 18.4320MHZ 18PF SMD; CategoryPassive components; File Size65KB，1 Pages; ManufacturerEPSON; Websitehttp://www.epsondevice.com; Environmental Compliance

Download Datasheet Parametric View All

MA-306 18.4320M-C0:ROHS Overview

CRYSTAL 18.4320MHZ 18PF SMD

MA-306 18.4320M-C0:ROHS Parametric

Parameter Name	Attribute value
type	MHz crystal
frequency	18.432MHz
frequency stability	±30ppm
frequency tolerance	±50ppm
load capacitance	18pF
ESR (equivalent series resistance)	60 Ohms
Operating mode	basic harmony
Operating temperature	-20°C ~ 70°C
grade	-
Installation type	surface mount
Package/casing	4-SOJ, 5.50mm pitch
size/dimensions	0.315" long x 0.126" wide (8.00mm x 3.20mm)
Height - Installation (maximum)	0.100"（2.54mm）

Preview

Download Datasheet

View All

Product Configuration System

MHz Range Crystal Units

MA‐306

Crystal Package Type:

MA‐306: Miniature 4pin “J”

lead SMD, 2.54mm Ht.

25.0000M

‐

PURE SN

Frequency Tolerance@25C

Blank: +/‐50ppm

Frequency Range

14.31818 & 17.7340 ~ 41.0000MHz

M: In MHz to 4 Decimal Places

Load Capacitance

B: 16.0pF

C: 18.0pF

F: Series

G: 20.0pF

K: 10.0pF

W: 12.0pF

Packaging

Tape and Reel Qty

Blank: Bulk

3: 250pcs/reel

0: 1000pcs/reel

5: 3000pcs/reel

PURE SN

ROHS

Blank = Not RoHs Compliant

NOTE:

If you require a load capacitance other than the above listed,

please contact your EEA representative for assistance.
