EG-2102CB 156.2500M-LGPAL3

Description
OSC SO 156.2500MHZ LVDS SMD
CategoryPassive components
File Size361KB,2 Pages
ManufacturerEPSON
Websitehttp://www.epsondevice.com
Environmental Compliance
Download Datasheet Parametric View All

EG-2102CB 156.2500M-LGPAL3 Overview

OSC SO 156.2500MHZ LVDS SMD

EG-2102CB 156.2500M-LGPAL3 Parametric

Parameter NameAttribute value
typeSO(SAW)
frequency156.25MHz
Functionenable/disable
outputLVDS
Voltage - Power3.3V
frequency stability±50ppm
Operating temperature0°C ~ 70°C
Current - Power (maximum)30mA
grade-
Installation typesurface mount
Package/casing6-SMD, no leads
size/dimensions0.197" long x 0.126" wide (5.00mm x 3.20mm)
Height - Installation (maximum)0.061"(1.55mm)
Current - Power (disabled) (maximum)15mA
Crystal oscillator
Product Number (please contact us)
LOW-JITTER SAW OSCILLATOR (SPSO)
OUTPUT : LV-PECL, LVDS
EG-2121CB P: X1M000211xxxx00
EG-2121CB L: X1M000231xxxx00
EG-2102CB P: X1M000201xxxx00
EG-2102CB L: X1M000221xxxx00
EG - 2121
/
2102CB
:
:
:
Output
:
Function
:
External
dimensions
:
Frequency
range
Supply
voltage
100 MHz to 700 MHz
2.5 V

EG-2121CB
3.3 V

EG-2102CB
LV-PECL or LVDS
Output enable (OE)
5.0 × 3.2 × 1.4 mm
Actual size
Low
jitter and low phase noise by SAW unit.
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Operating temperature
Frequency tolerance
Current consumption
Disable current
Symmetry
Output voltage (LV-PECL)
V
OL
V
OD
dV
OD
V
OS
dV
OS
L_ECL
L_LVDS
V
IH
V
IL
tr / tf
t_str
0.23 ps Max.
0.22 ps Max.
0.21 ps Max.
0.18 ps Max.
0.16 ps Max.
0.14 ps Max.
0.10 ps Max.
10
10
-6
/ year Max.
Symbol
f
0
V
CC
T_stg
T_use
f_tol
ICC
I_dis
SYM
V
OH
LV-PECL
EG-2121CB P
EG-2102CB P
LVDS
EG-2121CB L
EG-2102CB L
Conditions / Remarks
Please contact us about available frequencies.
Storage as single product.
100 MHz to 700 MHz
2.5 V
0.125
V
3.3 V
0.33
V
2.5 V
0.125
V
3.3 V
0.33
V
-55
C
to +125
C
P:0
C
to +70
C
,R:-5
C
to +85
C
,S:-20
C
to +70
C
G:
50
10
-6
,H:
100 
10
-6
60 mA Max.
30 mA Max.
2 mA Max.
15 mA Max.
45 % to 55 %
1.55 V Typ.
2.35 V Typ.
V
CC
-1.025 V to V
CC
-0.88 V
0.80 V Typ.
1.60 V Typ.
V
CC
-1.81 V to V
CC
-1.62 V
350 mV Typ, 247 mV to 454 mV
50 mV Max.
1.25 V Typ, 1.125 V to 1.375 V
150 mV Max.
50
100
70 % V
CC
Min.
30 % V
CC
Max.
400 ps Max.
10 ms Max.
0.27 ps Max.
0.24 ps Max.
0.23 ps Max.
0.19 ps Max.
0.16 ps Max.
0.14 ps Max.
0.10 ps Max.
OE=V
CC
, L_ECL=50
or L_LVDS=100
OE=GND
At outputs crossing point
DC characteristics
V
OD1
, V
OD2
dV
OD
=
V
OD1
-V
OD2
DC characteristics
V
OS1
, V
OS2
dV
OS
=
V
OS1
-V
OS2
Terminated to V
CC
-2.0 V
Connected between OUT to
OUT
OE terminal
Between 20 % and 80 % of (V
OH
-V
OL
).
Between 20 % and 80 %of Differential Output Peak
to Peak voltage.
Time at minimum supply voltage to be 0 s
100 MHz
f
0
150 MHz
150 MHz
f
0
200 MHz
200 MHz
f
0
300 MHz
Offset frequency:
300 MHz
f
0
400 MHz
12 kHz to 20 MHz
400 MHz
f
0
500 MHz
500 MHz
f
0
600 MHz
600 MHz
f
0
700 MHz
+25
C,
First year, V
CC
=2.5 V,3.3 V
Output voltage (LVDS)
Output load condition
(ECL) / (LVDS)
Input voltage
Rise time / Fall time
Start-up time
Phase Jitter
tPJ
Frequency aging
Product Name
(Standard form)
f_aging
EG-2121 CB 212.500000MHz P H P A (⑤⑥⑦:
GRA, GSA are not available)
④⑤⑥⑦
⑤Frequency
tolerance
①Model
②Package
type
③Frequency
G
±50 × 10
-6
④Output(P:LV-PECL,
L:LVDS)
H
±100 × 10
-6
⑤Frequency
tolerance
⑥Operating
temperature
⑦Frequency aging
(A*1: Frequency tolerance include aging, N*2: Frequency tolerance exclude aging)
⑥Operating
temp.
P
0 to +70°C
R
-5 to +85°C
S
-20 to +70°C
*1 This includes initial frequency tolerance, temperature variation, supply voltage variation, reflow drift, and aging(+25
C,10
years).
*2 This includes initial frequency tolerance, temperature variation, supply voltage variation, and reflow drift (except aging).
External dimensions
0.64
#6
#5
#4
3.2
0.2
#4
#5
#6
0.6 1.3
(Unit:mm)
Footprint (Recommended)
0.84
(Unit:mm)
E
212.50P
1P 1X1A
#1
#2
#3
5.0
0.2
#3
1.4
0.15
#2
1.27
#1
2.54
OE pin = HIGH : Specified frequency output.
OE pin = LOW : Output is high impedance
#2 and #3 are connected to the cover.
Pin map
Pin
1
2
3
4
5
6
Connection
OE *
GND
GND
OUT
OUT
V
CC
2.0
1.27
2.54
*) Standby function built-in.
To maintain stable operation, provide a 0.01 µF to
0.1 µF by-pass capacitor at a location as near as
possible to the power source terminal of the crystal
product (between V
CC
- GND).
1.6
