SSM6N16FU
TOSHIBA Field Effect Transistor Silicon N Channel MOS Type
SSM6N16FU
High Speed Switching Applications
Analog Switch Applications
•
•
Suitable for high-density mounting due to compact package
Low on resistance: R
on
= 3.0
Ω
(max) (@V
GS
= 4 V)
: R
on
= 4.0
Ω
(max) (@V
GS
= 2.5 V)
: R
on
= 15
Ω
(max) (@V
GS
= 1.5 V)
Unit: mm
(Q1, Q2 Common)
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Drain-Source voltage
Gate-Source voltage
Drain current
DC
Pulse
Symbol
V
DS
V
GSS
I
D
I
DP
P
D
(Note 1)
T
ch
T
stg
Rating
20
±10
100
200
200
150
−55~150
Unit
V
V
mA
mW
°C
°C
Drain power dissipation (Ta
=
25°C)
Channel temperature
Storage temperature range
JEDEC
JEITA
TOSHIBA
―
―
2-2J1C
Note:
Using continuously under heavy loads (e.g. the application of
Weight:
g
high temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating
conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Total rating
Marking
6
5
4
Equivalent Circuit
6
5
4
Q1
DS
Q2
1
2
3
1
2
3
Handling Precaution
When handling individual devices (which are not yet mounting on a circuit board), be sure that the environment
is protected against electrostatic electricity. Operators should wear anti-static clothing, and containers and other
objects that come into direct contact with devices should be made of anti-static materials.
Start of commercial production
2001-03
1
2014-03-01
SSM6N16FU
