Technical Data
2040
Effective
June
2017
Supersedes
August
2013
AGW
1/4” x 7/8” Fast-acting glass tube fuses
Ordering
information
•
Specify product code
•
Insert packaging code prefix before part number, E.g., BK/
AGW-1
Product features
•
•
•
•
Fast-acting
1/4” x 7/8” (6.3 x 22.2mm) physical size
Glass tube, nickel-plated brass endcap construction
Mounts in in-line holders HHB (data sheet # 2103),
HHK, HRK (data sheet # 2111) or PCB fuse clips for
1/4" fuses (1A1119, 1A1120, 1A1907, 1A3398,
1A4533 and 1A4534 - data sheet # 2131)
AGW-1
1
AGW-1-⁄
2
AGW-2
1
AGW-2-⁄
2
AGW-3
AGW-4
AGW-5
AGW-6
1
AGW-7-⁄
2
AGW-10
AGW-15
AGW-20
AGW-25
AGW-30
Part Number
(Amps)
Voltage Rating
Vac
32
32
32
32
32
32
32
32
32
32
32
32
32
32
Specifications
Interrupting Rating (amps)
at Rated Voltage AC
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
Typical DC Cold Resistance
(W)*
Lower
Upper
0.100
0.060
0.042
0.029
0.027
0.018
0.013
0.010
0.009
0.006
0.003
0.002
0.002
0.001
0.135
0.080
0.056
0.040
0.036
0.024
0.018
0.014
0.012
0.008
0.005
0.003
0.003
0.002
* DC Cold Resistance (Measured at <10% of rated current)
Effective
June
2017
Technical Data
2040
AGW
1/4” x 7/8” Fast-acting glass tube fuses
Dimensions - in
Time-Current Curves
0.88"
0.25"
Packaging Code Pre x
BK
Description
100 fuses packed into a cardboard carton
Packaging Code
Life Support Policy: Eaton does not authorize the use of any of its products for use in life support devices or systems without the express written
approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly
used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
Eaton reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Eaton also
reserves the right to change or update, without notice, any technical information contained in this bulletin.
Eaton
Electronics Division
1000 Eaton Boulevard
Cleveland, OH 44122
United States
www.eaton.com/electronics
© 2017 Eaton
All Rights Reserved
Printed in USA
Publication No.
2040 BU-SB13900
June
2017
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
