FEATURES
APPLICATIONS
Very fast charge/discharge
–
High power density
–
IEC 62391
compliant
–
Circuit board mountable
Battery backup/ alternative
–
Pulse power
–
Energy harvesting
–
LED
Displays
–
Mechanical actuators
–
Audio systems
-40°C to +60°C
-40°C to +70°C
+30%/-10% (Q tolerance), +20%/-20% (M tolerance)
+10%/-10% (K tolerance), +50%/-20% (S tolerance)
5.5
5.7
1 second discharge to ½ WVDC
5 second discharge to ½ WVDC
72 hours,25°C
Operating Temperature Range
Storage Temperature
Capacitance Tolerance
@ 20°C
WVDC
Surge Voltage
SVDC
Maximum Current
Operating Current
Leakage Current
Life Time
2.7
2.8
See standard part listing
See standard part listing
See standard part listing
Capacitance change
ESR
Leakage current
1000 hours with rated voltage applied at 60°C
+30% of initially measured values
<200% of initially specified values
< specified maximum value
+30% of initially measured values
<200% of initially specified values
1000 hours with no voltage applied at 60°C
Shelf Life
Life Cycles
( 25°C) 1 cycle= Charge to WVDC for
20s, constant voltage charging for
10s, discharge to ½ WVDC for 20s,
rest for 10 s
Capacitance change
ESR
Capacitance change
ESR change
500,000 cycles
+30% of initially measured values
<200% of initially specified values
D < 18mm
D
4
S
1.5
d
0.45
L
1
=L+1.5mm
D
1
=D+05mm
S
1
=S+0.5mm
Lead spacing VS. Case diameter
8(L<20)
8(L>20)
10
16
3.5
3.5
5.0
7.5
0.5
0.6
0.6
0.8
18
7.5
0.8
Aug-17
