Plastic Film Capacitors
Film Chip Capacitor
Type:
ECPU(B)
*Production volume is currently limited.
Please cousult with Panasonic about
Stacked dielectric with inner electrode and simple
mold-less construction
►Features
■
Low ESR
■Max.
capacitance values 1.0µF
■
Smallest package size in film capacitors 3216/1.0µF
■For
reflow soldering
►Recommended
Applications
■
Noise suppressor
■
Coupling circuit for Audio
►Explanation
of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
P
U
Rated voltage
Capacitance
Cap. Tol.
B
Suffix
5
Suffix
Product code
Dielectric &
construction
1E
►Specification
Category temp.range
(Including temperature-rise on unit surface)
25VDC
J
K
+/-5%
+/-10%
Tape width
5
8mm
-40 to +105 degree C
25VDC
(Derating of rated voltage by 2.5%/degree C more than 85 degree C)
0.0068µF to 1.0µF (E12)
+/-5%(J), +/-10%(K)
Between terminals : Rated volt. (VDC)X150% , 1min
1.5% max. (20 degree C , 1kHz)
0.0068µF - 0.33µF : 1000MΩ min. (20 degree C , 25VDC , 60s)
0.39µF - 1.0µF : 300MΩ • µFmin. (20 degree C , 25VDC , 60s)
Reflow soldering : 260 degree C max. and 90s max. at more than 220 degree C
(Temp. at cap. Surface)
Rated voltage
Capacitance range
Capacitance tolerance
Withstand voltage
Dissipation factor
Insulation resistance
Soldering conditions
►Construction
►Dimensions
in mm (not to scale)
L+/-0.2
W+/-0.2
(H+/-0.15)**
(W+/-0.15)**
Size code
H+/-0.2
K0
J1
J2
H1
H2
H3
L
1.6
W
0.8
H
0.6
e
g
0.40 min.0.4
0.45 min.0.6
0.45 min.0.6
0.65 min.1.0
0.65 min.1.0
0.65 min.1.0
2.0 1.25 0.8
2.0 1.25 1.0
3.2
3.2
3.2
1.6
1.6
1.6
0.8
1.0
1.4
Element
(stacked)
Outer
electrode
e+/-0.3
(e+/-0.25)*
(e+/-0.2)**
g
e+/-0.3
(e+/-0.25)*
(e+/-0.2)**
* To be applied only for size code J1 & J2
** To be applied only for size code K0
►Taping
Specification for Automatic Mounting
Refer to the taping specifications.
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt safety arises from this product, please inform us immediately for technical consultation without fail.
-1-
Plastic Film Capacitors
►Rating
, Dimensions & quantity / Reel
■
Capacitance tolerance : +/- 5%(J), +/- 10%(K),
Cap.
(
µF
)
Rated volt. 25VDC
Part No.
ECPU1E682( )B5
ECPU1E822( )B5
ECPU1E103( )B5
ECPU1E123( )B5
ECPU1E153( )B5
ECPU1E183( )B5
ECPU1E223( )B5
ECPU1E273( )B5
ECPU1E333( )B5
ECPU1E393( )B5
ECPU1E473( )B5
ECPU1E563( )B5
ECPU1E683( )B5
ECPU1E823( )B5
ECPU1E104( )B5
ECPU1E124( )B5
ECPU1E154( )B5
ECPU1E184( )B5
ECPU1E224( )B5
ECPU1E274( )B5
ECPU1E334( )B5
ECPU1E394( )B5
ECPU1E474( )B5
ECPU1E564( )B5
ECPU1E684( )B5
ECPU1E824( )B5
ECPU1E105( )B5
Dimensions (mm)
0.0068
0.0082
0.01
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.1
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
L
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
2.0
2.0
2.0
2.0
2.0
2.0
2.0
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
W
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
H
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
1.0
1.0
1.0
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.4
1.4
1.4
Size code
Q’ty
K0
K0
K0
K0
K0
K0
K0
K0
K0
K0
J1
J1
J1
J1
J2
J2
J2
H1
H1
H1
H1
H1
H2
H2
H3
H3
H3
4000
3000
2000
►Example
for Land Dimensions (mm)
Electrode
Size code
C
K0
J1,J2
H1,H2,H3
Land dimensions
Reflow soldering
A
B
C
0.6
2.0
0.7
0.8
2.4
1.1
1.8
3.6
1.4
Land
A
B
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt safety arises from this product, please inform us immediately for technical consultation without fail.
-2-
