FR304G A0G

Description
DIODE GEN PURP 400V 3A DO201AD
Categorysemiconductor    Discrete semiconductor
File Size350KB,4 Pages
ManufacturerTaiwan Semiconductor
Websitehttp://www.taiwansemi.com/
Environmental Compliance
Download Datasheet Parametric View All

FR304G A0G Overview

DIODE GEN PURP 400V 3A DO201AD

FR304G A0G Parametric

Parameter NameAttribute value
Diode typestandard
Voltage - DC Reverse (Vr) (Maximum)400V
Current - average rectification (Io)3A
Voltage at different If - Forward (Vf1.3V @ 3A
speedFast recovery = < 500 ns, > 200mA (Io)
Reverse recovery time (trr)150ns
Current at different Vr - Reverse leakage current5µA @ 400V
Capacitance at different Vr, F30pF @ 4V,1MHz
Installation typeThrough hole
Package/casingDO-201AD, axial
Supplier device packagingDO-201AD
Operating Temperature - Junction-55°C ~ 150°C
FR301G - FR307G
Taiwan Semiconductor
CREAT BY ART
3A, 50V - 1000V Glass Passivated Fast Recovery Rectifiers
FEATURES
- Glass passivated chip junction
- High current capability, Low VF
- High reliability
- High surge current capability
- Low power loss, high efficiency
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
MECHANICAL DATA
Case:
DO-201AD
Molding compound, UL flammability classification rating 94V-0
Part No. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Pure tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Weight:
1.2 g (approximately)
DO-201AD
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@3A
Maximum reverse current @ rated V
R
Maximum reverse recovery time (Note 2)
Typical junction capacitance (Note 3)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
T
J
=25°C
T
J
=125°C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
t
rr
C
J
R
θJA
T
J
T
STG
150
30
35
- 55 to +150
- 55 to +150
FR
301G
50
35
50
FR
302G
100
70
100
FR
303G
200
140
200
FR
304G
400
280
400
3
125
1.3
5
100
250
500
FR
305G
600
420
600
FR
306G
800
560
800
FR
307G
1000
700
1000
UNIT
V
V
V
A
A
V
μA
ns
pF
°C/W
°C
°C
Note 1: Pulse Test with PW=300μs, 1% Duty Cycle
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Document Number: DS_D1410036
Version: G15
