12F(R) SERIES
STANDARD RECOVERY DIODE
V
RRM
= 100-1200V, I
F(AV)
= 12A ,VF = 1.26 Volt.
Symbol
A
Cathode to Stud Shown
(Anode to Stud add Suffix R)
K
MAXIMUM RATINGS
(Tj = 25 C unless stated otherwise)
O
Add Prefix"A" for avalanche 400-1200V
12F(R)
-10
100
12F(R)
-20
200
12F(R)
-40
400
12F(R)
-60
600
12F(R)
-80
800
12F(R)
-100
1000
12F(R)
-120
1200
Symbol
Parameter
Repetitive Peak Reverse Voltage
Maximum Average On-State Current
Peak Forward Surge Current 8.3mS
Maximum I
2
T for Fusing 8.3ms
Maximum Storage Temperature Range
Maximum Junction Temperature Range
V
RRM
I
F
(AV)
I
FSM
I
2
T
T
(STG)
Tj
Unit
Volt
Amp
Amp
12.0 at tc=144
O
C
235
226
-65 to +200
-65 to +175
A
2
/S
O
C
C
O
ELECTRICAL CHARACTERISICS at
Parameter
Maximum Forward Voltage
Repetitive Peak Reverse Current
Tj = 25 C Maximum. Unless stated Otherwise
Condition
Symbol
V
FM
I
RRM
P
R
R
TH (J-c)
M
T
Wt
I
FM
= 38 Amps
V
R
= V
RRM
. t
J
=175
O
C
tp= 10µs rect wave at tj
Max
Value
Min
Typ
Max
1.26
12.0
7.0
2.0
1.2
7.0
Unit
Volt
mA
kW
O
Maximum non-repetitive peak reverse power
(Avalanche Version
)
Thermal Resistance (Junction to Case)
Mounting Torque
Weight
C/W
NM
grms
a
b
c
Dim
a
b
c
d
e
f
g
j
h
j
k
m
DIMENSIONS
Millimetres
Inches
Min
Max
Min
Max
12.82
0.505
0.020
0.424
0.065
0.437
0.310
0.413
0.100
0.51
1.65
10.77 11.20
7.87
10.49
2.54
4.44
20.82
11.50
10.29
e
d
f
0.060
0.075
1.53
Polarity Symbol
g
0.175 1.91
10 -32 UNF3A
0.600 0.820 15.24
0.453 10.72
0.405
0.422
m
k
h
MetalCase
DO-4
