1.25mm
(0.049") PITCH CONNECTOR
FPC/FFC Connector
Housing
DIP, ZIF(Vertical Through Hole)
Straight
12516HS Series
Material
I/NO
1
2
3
DESCRIPTION
HOUSING
ACTUATOR
TERMINAL
TITLE
12516HS
12516AS
12516TS
MATERIAL
PBT, UL 94V Grade
PBT, UL 94V Grade
Phosphor Bronze & Tin plated
Available Pin
12516HS- 04A00
12516HS- 05A00
12516HS- 06A00
12516HS- 07A00
12516HS- 08A00
12516HS- 09A00
12516HS- 10A00
12516HS- 11A00
12516HS- 12A00
12516HS- 13A00
12516HS- 14A00
12516HS- 15A00
12516HS- 16A00
12516HS- 17A00
12516HS- 18A00
12516HS- 19A00
12516HS- 20A00
12516HS- 21A00
12516HS- 22A00
12516HS- 23A00
12516HS- 24A00
12516HS- 25A00
12516HS- 26A00
12516HS- 27A00
12516HS- 28A00
12516HS- 29A00
12516HS- 30A00
PARTS NO.
A
1.25 (PITCH)
C
B
12.75
14.00
15.25
16.50
17.75
19.00
20.25
21.50
22.75
24.00
25.25
26.50
27.75
29.00
30.25
31.50
32.75
34.00
35.25
36.50
37.75
39.00
40.25
41.50
42.75
44.00
45.25
A
6.35
7.60
8.85
10.10
11.35
12.60
13.85
15.10
16.35
17.60
18.85
20.10
21.35
22.60
23.85
25.10
26.35
27.60
28.85
30.10
31.35
32.60
33.85
35.10
36.35
37.60
38.85
B
3.75
5.00
6.25
7.50
8.75
10.0
11.25
12.5
13.75
15.0
16.25
17.5
18.75
20.0
21.25
22.5
23.75
25.0
26.25
27.5
28.75
30.0
31.25
32.5
33.75
35.0
36.25
C
YH
5.0
A
Specification
Voltage Rating
Current Rating
Operating Temperature
Contact Resistance
Withstanding Voltage
Insulation Resistance
Applicable Wire
Applicable P.C.B
Applicable FPC/FFC
Solder Height
Crimp Tensile Strength
UL FILE NO
11.2
(5.65)
ITEM
AC/DC 250V
AC/DC 1A
-25℃~+85℃
SPEC
0.50
2.0 (1.28)
30mΩ MAX
AC500V/1min
500MΩ MIN
-
1.2 ~ 1.6mm
0.30±0.05mm
-
-
-
C
±0.05
1.25
±0.05
11.2
3.0
0.6
SUPPORT PLATE
3.5
5.4
1.25±0.05
0.8±0.05
C
0.38±0.02
2.0
±0.05
0.8
BASE PIN
Ø0.9
PC
PC
T
Actuator Open
Actuator Close
PCB LAYOUT
PCB ASS'Y
T
8.6
APPLICABLE FFC/FPC
