HES5A-SST-VL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Module/solution> HES5A-SST-VL

HES5A-SST-VL: DescriptionETHERNET SWITCH DIN-RAIL UNMANAG; CategoryModule/solution; File Size341KB，3 Pages; ManufacturerKavlico; Environmental Compliance

Download Datasheet Parametric View All

HES5A-SST-VL Overview

ETHERNET SWITCH DIN-RAIL UNMANAG

HES5A-SST-VL Parametric

Parameter Name	Attribute value
type	Switch - Unmanaged
Configuration	Fixed
Number of ports	5
copper port	4
Copper type	10/100
Fiber optic port	1
Fiber type	100BASE-FX (single mode)
SFP/XFP port	-
SFP/XFP type	-
Connector type	RJ45，ST
Voltage - input	10 ~ 24VAC、12 ~ 36VDC
Intrusion protection	IP30
Installation type	DIN rail
Operating temperature	-10°C ~ 60°C

Preview

Download Datasheet

View All

HES5A/8A Series HE0001DU1001ds - 1/3

Product

Information

HES5A/8A Series

5 and 8-port Din-rail Unmanaged Ethernet Switches

Features

UL/cUL Class I Division 2 Groups A,B,C, and D

Shock, vibration, tested

Henrich Electronics Corporation

Main Office

Tel: 860-487-9869

Fax: 860-487-9478

www.henrich-inc.com

10/100M, full/half duplex, MDI/MDI-X (Auto-negotiate)

Industrial IP30 rated DIN rail case with 6 way panel mount options

Dual power inputs, 12 to 36 VDC and 10 to 24 VAC

Operating temperature:-10°C to 60°C (Standard); -40°C to 75°C (W models)

100% burn in testing

HES5A/8A Series HE0001DU1001ds - 3/3

Ordering Information

HES5A

HES5A-VL

HES5A-VLW

HES5A-SC-VL

HES5A-SC-VLW

HES5A-SSC-VL

HES5A-SSC-VLW

HES5A-2SC-VL

HES5A-2SC-VLW

HES5A-2SSC-VL

HES5A-2SSC-VLW

Din-rail Unmanaged, 5 x 100Mbps Copper Port, Industrial Temperature -10~+60°C, Power Input 12~36VDC or

10~24VAC

Din-rail Unmanaged, 5 x 100Mbps Copper Port, Industrial Wide Temperature -40~+75°C, Power Input

12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 1 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 1 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 1 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 1 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 3 x 100Mbps Copper Port, 2 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 3 x 100Mbps Copper Port, 2 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 3 x 100Mbps Copper Port, 2 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 3 x 100Mbps Copper Port, 2 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Note: All of the Above Products SC Connector can be replaced by ST Connector

HES8A

HES8A-VL

HES8A-VLW

HES8A-2SC-VL

HES8A-2SC-VLW

HES8A-2SSC-VL

HES8A-2SSC-VLW

HES8A-4SC-VL

HES8A-4SC-VLW

HES8A-4SSC-VL

HES8A-4SSC-VLW

Din-rail Unmanaged, 8 x 100Mbps Copper Port, Industrial Temperature -10~+60°C, Power Input 12~36VDC or

10~24VAC

Din-rail Unmanaged, 8 x 100Mbps Copper Port, Industrial Wide Temperature -40~+75°C, Power Input

12~36VDC or 10~24VAC

Din-rail Unmanaged, 6 x 100Mbps Copper Port, 2 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 6 x 100Mbps Copper Port, 2 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 6 x 100Mbps Copper Port, 2 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 6 x 100Mbps Copper Port, 2 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 4 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 4 x 100Mbps Multi-Mode Fiber Port with SC Connectors,

2KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 4 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Temperature -10~+60°C, Power Input 12~36VDC or 10~24VAC

Din-rail Unmanaged, 4 x 100Mbps Copper Port, 4 x 100Mbps Single-Mode Fiber Port with SC Connectors,

20KM, Industrial Wide Temperature -40~+75°C, Power Input 12~36VDC or 10~24VAC

Note: All of the Above Products SC Connector can be replaced by ST Connector

Tel: 860-487-9869

www.henrich-inc.com
