Ferrites and accessories
P9×5
Core and accessories
Series/Type:
Date:
B65517, B65522, B65524, B65518
July 2017
EPCOS AG 2017. Reproduction, publication and dissemination of this publication, enclosures hereto and the
information contained therein without EPCOS’ prior express consent is prohibited.
EPCOS AG is a TDK Group Company.
P9
5
Core and accessories
Individual parts
Yoke
Part no.
B65518
Page
6
Core
B65517
3
Coil former
B65522
4
Insulating washer
Core
B65517
3
Terminal carrier
with thread
B65518
6
Example of an assembly set
for printed circuit boards
Also available:
SMD coil former
B65524
5
Please read
Cautions and warnings
and
Important notes
at the end of this document.
2
7/17
P9
Core
5
B65517
■
To IEC 62317-2
■
Delivery mode: sets
Magnetic characteristics
(per set)
with center without
hole
center hole
l/A
l
e
A
e
A
min
V
e
1.25
12.5
10
—
125
1.13
13.4
11.9
9.3
159
mm
–1
mm
mm
2
mm
2
mm
3
Approx. weight
(per set)
m
0.8
1.0
g
Gapped
(A
L
values/air gaps examples)
Material
A
L
value
nH
K1
M33
N48
25 3%
40 3%
63 3%
100
160
200
250
3%
3%
3%
5%
s
approx.
mm
0.45
0.26
0.20
0.10
0.06
0.04
0.03
e
Ordering code
1)
-D with center hole
-T with threaded sleeve
B65517+0025A001
B65517+0040A001
B65517D0063A033
B65517+0100A048
B65517+0160A048
B65517D0200A048
B65517D0250J048
25
40
63
100
159
200
249
Ungapped
Material
A
L
value
nH
N48
N30
T38
1300 +30/–20%
2500 +30/–20%
5500 +40/–30%
1290
2490
4930
e
Ordering code
-D with center hole
-W without center hole
B65517D0000R048
B65517D0000R030
B65517W0000Y038
Other A
L
values/air gaps and materials available on request – see Processing remarks on page 7.
1) Replace the + by the code letter ”D“ or ”T“ for the required version.
Please read
Cautions and warnings
and
Important notes
at the end of this document.
3
7/17
P9
5
B65522
Accessories
Coil former
Standard:
Material:
to IEC 62317-2
GFR polyterephthalate (UL 94 V-0, insulation class to IEC 60085:
F max. operating temperature 155 °C), color code black
Valox 420-SE0
®
E207780 (M) , SABIC JAPAN LLC
see Processing notes, 2.1
Ordering code
A
N
mm
2
3.6
l
N
mm
19.2
A
R
value
183
Winding:
Coil former
Sections
1
B65522B0000T001
Coil former
Please read
Cautions and warnings
and
Important notes
at the end of this document.
4
7/17
P9
5
B65524
Accessories
SMD coil former with gullwing terminals
GFR liquid crystal polymer (UL 94 V-0, insulation class to IEC 60085:
F max. operating temperature 155 °C), color code black
Sumika Super E4008
®
E54705 (M) , SUMITOMO CHEMICAL CO LTD
Solderability: to IEC 60068-2-58, test Td, method 6 (Group 3): 245 °C, 3 s
Resistance to soldering heat: to IEC 60068-2-58, test Td, method 6 (Group 3): 255 °C, 10 s
permissible soldering temperature for wire-wrap connection on coil former: 400 °C, 1 s
Winding:
see Processing notes, 2.1
Sections
1
A
N
mm
2
3.4
3.4
l
N
mm
19.2
19.2
A
R
value
194
194
Terminals
4
8
Ordering code
B65524C1004T001
B65524C1008T001
Material:
In the 4-terminal version terminals 2, 3, 6 and 7 are omitted.
