MCC
Features
•
•
•
•
•
•
•
•
•
TM
Micro Commercial Components
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
ESD5V0LP
For sensitive ESD protection
Excellent clamping capability
Low leakage
ESD rating of class 3(>16KV)per Human Body Mode
For space saving application
Fast response,response time less than 1ns.
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
5.0 Volts
ESD Protection
Device
SOD-882
D
Maximum Ratings
•
•
Operating Junction &StorageTemperature: -55°C to +150°C
Maximum Thermal Resistance:
1250°C/W
Junction To Ambient
Symbol
Air
Contact
Pd
Limits
f30
f30
16
100
unit
KV
KV
mw
C
L
H
A
Parameter
IEC61000-4-2(ESD)
B
ESD Voltage per human body mode
Power Dissipation
F
G
E
Internal Structure
DIM
A
B
C
D
E
F
G
H
L
_
+
NOTE
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
0.018
0.022
0.45
0.55
0.000
0.003
0.01
0.07
0.019REF.
0.470REF.
0.037
0.041
0.95
1.05
0.022
0.026
0.55
0.65
0.017 REF.
0.420 REF.
0.011
0.015
0.27
0.37
0.001 REF.
0.030 REF.
0.013
0.017
0.34
0.44
Suggested Solder
Pad Layout
(mm)
www.mccsemi.com
Revision:A
1 of
4
2014/03/04
MCC
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
TM
Micro Commercial Components
Symbol
I
PP
V
C
V
RWM
I
R
V
BR
I
T
P
pk
C
Parameter
Maximum Reverse Peak Pulse Current
Clamping Voltage @ I
PP
Working Peak Reverse Voltage
Maximum Reverse Leakage Current @ V
RWM
Breakdown Voltage @ I
T
Test Current
Peak Power Dissipation
Max. Capacitance @V
R
=0 and f =1MHz
ELECTRICAL CHARACTERISTICS
(Ta = 25°C unless otherwise noted
)
V
RWM
Device
Device
Marking
Max
ESD5V0LP
B
I
R
(μA)
@ V
RWM
Max
V
BR
(V) @ I
T
(Note
1)
Min
Max
I
T
P
pk
(W)
I
PP
(A)
(8x20 us)
mA
Typ
Max
V
C
(V)
C (pF)
@Max I
PP
Max
Typ
(V)
5.0
1.0
6.2
7.3
1.0
107
8.7
12.3
65
Note: 1.
V
BR
is measured with a pulse test current I
T
at an ambient temperature of 25°C.
www.mccsemi.com
Revision: A
2
of
4
2014/03/04
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
10Kpcs/Reel
