Product Data Sheet 4656 ZWU
4656 ZWU
INDEX
1
2
General ....................................................................................................................................................................... 3
Mechanics .................................................................................................................................................................. 3
2.1
2.2
G
ENERAL
............................................................................................................................................................. 3
C
ONNECTIONS
...................................................................................................................................................... 4
3
Operating Data .......................................................................................................................................................... 5
3.1
3.2
3.3
3.4
3.5
E
LECTRICAL
O
PERATING
D
ATA
.............................................................................................................................. 5
O
PERATING
D
ATA
- E
LECTRICAL
I
NTERFACE
-O
UTPUT
........................................................................................... 6
E
LECTRICAL
F
EATURES
........................................................................................................................................ 6
A
ERODYNAMIC
..................................................................................................................................................... 6
S
OUND
D
ATA
....................................................................................................................................................... 7
4
Environment .............................................................................................................................................................. 8
4.1
4.2
G
ENERAL
............................................................................................................................................................. 8
C
LIMATIC REQUIREMENTS
*)................................................................................................................................... 8
5
Safety ......................................................................................................................................................................... 9
5.1
5.2
E
LECTRICAL
S
AFETY
............................................................................................................................................. 9
A
PPROVAL
T
ESTS
................................................................................................................................................. 9
6
Reliability ................................................................................................................................................................... 9
6.1
G
ENERAL
............................................................................................................................................................. 9
07/15/2014
page
2 of 10
Product Data Sheet 4656 ZWU
1
General
Fan
clockwise
Air outlet over struts
Ball bearing
any
2,5
Fan type
Rotational direction looking at rotor
Airflow direction
Bearing system
Mounting position
Balancing grade
2
2.1
Mechanics
General
Width
Height
Depth
Diameter
Weight
Housing material
Impeller material
Max. torque when mounted across both mounting
flanges
Screw size
119,0 mm
119,0 mm
38,0 mm
0,0 mm
0,540 kg
Metal
Metal
wire outlet corner: 120 Ncm
remaining corners: 350 Ncm
ISO 4762 - M4 degreased, without an additional
brace and without washer
07/15/2014
page
3 of 10
Product Data Sheet 4656 ZWU
3
3.1
Operating Data
Electrical Operating Data
Normal air density = 1,2 kg/m3; Temperature 23°C +/- 3°C; Motor axis horizontal;warm-up
time before measuring 5 minutes (unless otherwise specified).
In the intake and outlet area should not be any solid obstruction within 0,5 m.
Measurement
conditions:
∆p
= 0: corresp. to free air flow (see section 3.4)
I:
corresp. to RMS line current
Features
Condition
Symbol
Frequency
∆p
= 0
f
Nominal voltage
Tolerance
Power consumption
Tolerance
Speed
Tolerance
∆p
= 0
n
∆p
= 0
P
∆p
= 0
U
N
+ 6,0 %
Values
50 Hz
230,0 V
- 10,0 %
+ 6,0 %
60 Hz
230,0 V
- 10,0 %
19,0 W
+- 10,0 %
2.650 1/min
+- 3,0 %
17,0 W
+- 10,0 %
3.100 1/min
+- 3,0 %
07/15/2014
page
5 of 10
