The Bridgelux SMD 3030 offers exceptional performance in a compact LED package. This mid power LED is hot-color
targeted which ensures that the LEDs fall within their specified color bin at the typical application conditions of 85°C.
With its broad lumen coverage and wide range of CCT options, the SMD 3030 provides unparalleled design-in flexibility
for indoor and outdoor lighting applications. Its high flux capability reduces the number of LEDs and enables industry
leading system level lumen per dollar. The SMD 3030 is ideal as a drop in replacement for emitters with an industry
standard 3.0mm x 3.0mm footprint.
Features
• Competitive efficacy and lumen per dollar
• Industry-standard 3030 footprint
• Excellent color maintenance
• 9 bin color control enables tight color control
• Superior luminous flux at maximum current for
reduced LED count
• Hot-color targeting ensures that color is within the
ANSI bin at the typical application conditions of 85°C
• Enables 3- and 5-step MacAdam ellipse custom
binning kits
• RoHS compliant and Lead free
• Multiple CCT and CRI configurations for a wide
range of lighting applications
Benefits
• Lower operating and manufacturing cost
• Ease of design and rapid go-to-market
• Uniform consistent white light
• Reliable and constant white point
• Environmentally friendly, complies with standards
• Design flexibility
SMD 3030
SMD 3030
Contents
Product Feature Map
Product Nomenclature
Product Test Conditions
Product Selection Guide
Performance at Commonly Used Drive Currents
Electrical Characteristics
Absolute Maximum Ratings
Product Bin Definitions
Performance Curves
Typical Radiation Pattern
Typical Color Spectrum
Mechanical Dimensions
Reliability
Reflowing Characteristics
Packaging
Design Resources
Precautions
Disclaimers
About Bridgelux
2
2
2
3
5
9
10
11
14
17
18
19
20
21
22
24
24
24
25
1
Product Feature Map
Bridgelux SMD LED products offer exceptional
performance and color quality all in a highly reliable, cost
effective, compact package. Our SMD products come in
industry standard package sizes and follow ANSI binning
standards.
These LEDs are optimized for cost and performance,
helping to ensure highly competitive system lumen
per dollar performance while addressing the stringent
efficacy and reliability standards required for modern
lighting applications.
Cathode Mark
Yellow phosphor Light
Emitting Surface (LES)
Product Nomenclature
The part number designation for Bridgelux SMD 3030 is explained as follows:
Product Test Conditions
Bridgelux SMD 3030 LEDs are tested and binned with a 10ms pulse of 150mA at T
j
(junction temperature)=T
sp
(solder point
temperature) =25°C. Forward voltage and luminous flux are binned at a T
j
=T
sp
=25°C, while color is hot targeted at a T
sp
of 85°C.
2
Product Selection Guide
The following product configurations are available:
Table 1:
Selection
Guide, Pulsed Measurement Data at 150mA
(T
j
=T
sp
=25°C)
Part Number
1,6
Nominal CCT
2
(K)
CRI
3, 5
Nominal
Drive Current
(mA)
Forward Voltage
4, 5
(V)
Min
Typical
Max
Minimum
Pulsed Flux
(lm)
4, 5, 7
Typical
Pulsed Flux
(lm)
4, 5
Typical
Power
(W)
Typical
Efficacy
(lm/W)
BXEM-27C0000-0-000
BXEM-27E0000-0-000
BXEM-27G0000-0-000
BXEM-30C0000-0-000
BXEM-30E0000-0-000
BXEM-30G0000-0-000
BXEM-35C0000-0-000
BXEM-35E0000-0-000
BXEM-35G0000-0-000
BXEM-40C0000-0-000
BXEM-40E0000-0-000
BXEM-40G0000-0-000
BXEM-50C0000-0-000
BXEM-50E0000-0-000
BXEM-50G0000-0-000
BXEM-57C0000-0-000
BXEM-57E0000-0-000
BXEM-57G0000-0-000
BXEM-65C0000-0-000
BXEM-65E0000-0-000
BXEM-65G0000-0-000
2700
2700
2700
3000
3000
3000
3500
3500
3500
4000
4000
4000
5000
5000
5000
5700
5700
5700
6500
6500
6500
70
80
90
70
80
90
70
80
90
70
80
90
70
80
90
70
80
90
70
80
90
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.25
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
110
100
80
110
110
90
110
110
90
120
110
90
120
110
90
120
110
90
120
110
90
123
117
98
126
123
103
129
125
105
133
127
108
133
127
108
133
127
108
133
126
108
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
131
125
105
134
131
110
138
133
112
142
135
115
142
135
115
142
135
115
142
134
115
Notes for Table 1:
1. The last 10 characters (including hyphens ‘-’) refer to nominal flux, nominal forward voltage, and color bins, respectively. “0000-0-000” denotes the full
distribution of flux, forward voltage, and 7 SDCM color.
Example: BXEM-30E0000-0-000 refers to the full distribution of flux, forward voltage, and color within a 3000K 7-step ANSI standard chromaticity
region with a minimum of 80CRI.
2. Product CCT is hot targeted at T
sp
= 85°C. Nominal CCT as defined by ANSI C78.377-2011.
3. Listed CRIs are minimum values and include test tolerance.
4. Products tested under pulsed condition (10ms pulse width) at nominal drive current where T
j
=T
sp
=25°C.
5. Bridgelux maintains a ±7.5% tolerance on luminous flux measurements, ±0.1V tolerance on forward voltage measurements, and ±2 tolerance on CRI
measurements for the SMD 3030.
6. Refer to Table 6 and Table 7 for Bridgelux SMD 3030 Luminous Flux Binning and Forward Voltage Binning information.
7. Minimum flux values at elevated temperatures are provided for reference only and are not guaranteed by 100% production testing.
