2SC4944-Y(TE85L,F)

Description
TRANS 2NPN 50V 0.15A USV
CategoryDiscrete semiconductor    The transistor
File Size246KB,4 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

2SC4944-Y(TE85L,F) Overview

TRANS 2NPN 50V 0.15A USV

2SC4944-Y(TE85L,F) Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instruction,
Reach Compliance Codeunknown
Maximum collector current (IC)0.15 A
Minimum DC current gain (hFE)120
Maximum operating temperature125 °C
Polarity/channel typeNPN
Maximum power dissipation(Abs)0.2 W
surface mountYES
Nominal transition frequency (fT)80 MHz
Base Number Matches1
2SC4944
TOSHIBA Transistor
Silicon NPN Epitaxial Type (PCT Process)
2SC4944
Audio Frequency General Purpose Amplefier Applications
Small package (dual type)
High voltage and high current: V
CEO
= 50 V, I
C
= 150 mA (max)
High h
FE
: h
FE
= 120 to 400
Excellent h
FE
linearity: h
FE
(I
C
= 0.1 mA)/h
FE
(I
C
= 2 mA) = 0.95 (typ.)
Complementary to 2SA1873
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C) (Q1, Q2 common)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
(Note 1)
T
j
T
stg
Rating
60
50
5
150
30
200
125
−55
to 125
Unit
V
V
V
mA
mA
mW
°C
°C
JEDEC
JEITA
TOSHIBA
2-2L1A
Note:
Weight: 6.2 mg (typ.)
Using continuously under heavy loads (e.g. the application of
high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to
decrease in the reliability significantly even if the operating conditions (i.e. operating
temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Total rating
Marking
Equivalent Circuit
(top view)
Start of commercial production
1992-07
1
2014-03-01

2SC4944-Y(TE85L,F) Related Products

2SC4944-Y(TE85L,F) 2SC4944-Y(T5LNSEIF 2SC4944-Y(T5RMAA,F 2SC4944-GR(TE85L,F
Description TRANS 2NPN 50V 0.15A USV Small Signal Bipolar Transistor, 0.15A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon Small Signal Bipolar Transistor, 0.15A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon TRANS NPN 50V 0.15A USV
Reach Compliance Code unknown unknow unknow -
Maximum collector current (IC) 0.15 A 0.15 A 0.15 A -
Minimum DC current gain (hFE) 120 120 120 -
Polarity/channel type NPN NPN NPN -
surface mount YES YES YES -
Nominal transition frequency (fT) 80 MHz 80 MHz 80 MHz -
Base Number Matches 1 1 1 -
