SENSE ......................................................................0.5V
Operating Ambient Temperature Range (Notes 3, 4)
LT3761E/LT3761E-1 ............................... –40 to 125°C
LT3761I/LT3761I-1 ................................. –40 to 125°C
LT3761H ................................................ –40 to 150°C
Storage Temperature Range .................. –65°C to 150°C
17
GND
MSE PACKAGE
16-LEAD PLASTIC MSOP
T
JMAX
= 125°C (E-, I-GRADES), T
JMAX
= 150°C (H-GRADE),
θ
JA
= 43°C/W,
θ
JC
= 4°C/W
EXPOSED PAD (PIN 17) IS GND, MUST BE SOLDERED TO PCB
orDer inFormaTion
http://www.linear.com/product/LT3761#orderinfo
LEAD FREE FINISH
TAPE AND REEL
PART MARKING*
PACKAGE DESCRIPTION
TEMPERATURE RANGE
LT3761EMSE#PBF
LT3761EMSE#TRPBF
3761
16-Lead Plastic MSOP
–40°C to 125°C
LT3761IMSE#PBF
LT3761IMSE#TRPBF
3761
16-Lead Plastic MSOP
–40°C to 125°C
LT3761HMSE#PBF
LT3761HMSE#TRPBF
3761
16-Lead Plastic MSOP
–40°C to 150°C
LT3761EMSE-1#PBF
LT3761EMSE-1#TRPBF
37611
16-Lead Plastic MSOP
–40°C to 125°C
LT3761IMSE-1#PBF
LT3761IMSE-1#TRPBF
37611
16-Lead Plastic MSOP
–40°C to 125°C
Consult LTC Marketing for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
For more information on tape and reel specifications, go to:
http://www.linear.com/tapeandreel/
Some packages are available in 500 unit reels through
designated sales channels with #TRMPBF suffix.
elecTrical characTerisTics
PARAMETER
V
IN
Minimum Operating Voltage
V
IN
Shutdown I
Q
V
IN
Operating I
Q
(Not Switching)
V
REF
Voltage
V
REF
Line Regulation
V
REF
Pull-Up Current
SENSE Current Limit Threshold
SENSE Input Bias Current
DIM/SS Pull-Up Current
DIM/SS Voltage Clamp
The
l
denotes the specifications which apply over the full operating
temperature range, otherwise specifications are at T
