HDSP-B0xE
18:88 and 88:88 0.56" Four Digit GaP HER
Seven Segment Display
Data Sheet
Description
The 18:88 and 88:88 0.56" Four Digit Seven Segment
Displays have surface painted in neutral gray for
enhanced on/off contrast. All devices are available in
either common anode or common cathode configuration
with untinted segments.
Features
•
Excellent appearance
•
Evenly illuminated segments
•
Gray face for optimum on/off contrast
•
Choice of colors: HER
•
Choice of character size: 0.56 inch
Package Dimensions
88:88 0.56" Four Digit Display
FRONT SIDE
2 –
∅1.70
(0.067)
RIGHT SIDE
7.80
(0.307)
PIN 12
+
6.00
(0.236)
PIN 8
+
10.00
A
14.22
(0.560)
19.10
(0.752)
15.24
(0.600)
F
E
B
G
C
D
DIGIT 1
F
E
A
G
A
BF
CE
D
DIGIT 4
A
G
B
C
B
DP3
F
DP2
G
C
D
E
D
+
PIN 1
+
PIN 7
DIGIT 2
DIGIT 3
12.7 x 3 = 38.10
(1.500)
51.20
(2.016)
BOTTOM SIDE
7.00
(0.276)
8.00
(0.315)
2.54 x 6 = 15.24
(0.600)
0.50
(0.020)
4.00
(0.157)
NOTE:
ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
UNLESS OTHERWISE STATED, TOLERANCES ARE ± 0.25 mm.
HDSP-B0xG Pkg Dimen a
Package Dimensions
18:88 0.56" Four Digit Display
FRONT SIDE
2 –
∅1.70
(0.067)
RIGHT SIDE
7.80
(0.307)
PIN 12
+
6.00
(0.236)
PIN 8
+
10.00
A
A
DP3
F
B
G
G BF
C
D
DIGIT 1
DP2
A
G
B
C
D
14.22
(0.560)
19.10
(0.752)
15.24
(0.600)
B
C
F
E
E
D
CE
+
PIN 1
+
PIN 7
DIGIT 2
DIGIT 3
DIGIT 4
12.7 x 3 = 38.10
(1.500)
51.20
(2.016)
BOTTOM SIDE
7.00
(0.276)
8.00
(0.315)
2.54 x 6 = 15.24
(0.600)
0.50
(0.020)
4.00
(0.157)
NOTE:
ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
UNLESS OTHERWISE STATED, TOLERANCES ARE ± 0.25 mm.
Pin Configuration
Pin
1
2
3
4
5
6
7
8
9
10
11
12
HDSP-B01E/B03E
Anode E
Anode D
Anode DP
Anode C
Anode G
Digit 4 Common Cathode
Anode B
Digit 3 Common Cathode
Digit 2 Common Cathode
Anode F
Anode A
Digit 1 Common Cathode
Function
HDSP-B0xG Pkg Dimen b
HDSP-B02E/B04E
Cathode E
Cathode D
Cathode DP
Cathode C
Cathode G
Digit 4 Common Anode
Cathode B
Digit 3 Common Anode
Digit 2 Common Anode
Cathode F
Cathode A
Digit 1 Common Anode
Internal Circuit Diagram
HDSP-B01E (Common Cathode)
DIGIT 1
12
DIGIT 2
9
DIGIT 3
8
DIGIT 4
6
B
C
A
11
B
7
C
4
D
2
E
1
F
10
G
5
DP
3
HDSP-B0xG Circuit Diag – Cathode
HDSP-B02E (Common Anode)
DIGIT 1
12
DIGIT 2
9
DIGIT 3
8
DIGIT 4
6
B
C
A
11
B
7
C
4
D
2
E
1
F
10
G
5
DP
3
HDSP-B0xG Circuit Diag – Anode
Internal Circuit Diagram
HDSP-B03E (Common Cathode)
DIGIT 1
12
DIGIT 2
9
DIGIT 3
8
DIGIT 4
6
A
11
B
7
C
4
D
2
E
1
F
10
G
5
DP
3
HDSP-B0xG Circuit Diag – Cathode
HDSP-B04E (Common Anode)
DIGIT 1
12
DIGIT 2
9
DIGIT 3
8
DIGIT 4
6
A
11
B
7
C
4
D
2
E
1
F
10
G
5
DP
3
HDSP-B0xG Circuit Diag – Anode
5
