Disconnect terminal block - UK 4-TG BK - 3073924
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Disconnect terminal block, Connection type: Screw connection, Cross section: 0.2 mm² - 4 mm², AWG: 24 - 12,
Nominal current: 16 A, Nominal voltage: 500 V, Length: 42.5 mm, Width: 6.2 mm, Color: black, Assembly: NS
35/7,5, NS 35/15, NS 32
The illustration shows the version in
gray
Key Commercial Data
Packing unit
GTIN
Custom tariff number
85369010
1
Technical data
General
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Connection in acc. with standard
Nominal current I
N
Maximum load current
Nominal voltage U
N
1
2
4 mm²
black
PA
V0
6 kV
3
III
I
IEC 60947-7-1
16 A
16 A (with 4 mm² conductor cross section)
500 V
02/25/2016 Page 1 / 5
https://www.phoenixcontact.com/us/products/3073924
Disconnect terminal block - UK 4-TG BK - 3073924
Technical data
General
Open side panel
Number of positions
Yes
1
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
Height NS 32
6.2 mm
42.5 mm
47 mm
54.5 mm
52 mm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
0.2 mm²
4 mm²
0.2 mm²
4 mm²
24
12
0.25 mm²
2.5 mm²
0.25 mm²
2.5 mm²
0.2 mm²
1.5 mm²
0.2 mm²
1.5 mm²
0.25 mm²
1.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1.5 mm²
sleeve, max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
Connection method
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
1.5 mm²
1.5 mm²
Screw connection
9 mm
A3
M3
0.5 Nm
02/25/2016 Page 2 / 5
https://www.phoenixcontact.com/us/products/3073924
Disconnect terminal block - UK 4-TG BK - 3073924
Technical data
Connection data
Tightening torque max
0.6 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
CSA
IEC 60947-7-1
V0
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
27141126
27141126
27141126
27141126
27141126
27141126
27141126
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000903
EC000903
EC000902
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39121410
Approvals
Approvals
Approvals
CSA / UL Recognized / cUL Recognized / ABS / EAC / cULus Recognized
02/25/2016 Page 3 / 5
