Fingerstock Gaskets
77-011
77-015
77-018
77-010
FINGERSTOCK GASKETS AND METAL GROUNDING PRODUCTS
As the world’s leading fabricator of fingerstock, Laird Technologies has developed highly
sophisticated, and often proprietary, shielding and grounding technology.
Our innovations are necessary to achieve outstanding combinations of performance parameters.
From a vast selection of product configurations, platings and mounting techniques, to a full range
of low compression force requirements and high transfer impedance characteristics, there is a
Laird Technologies gasket or grounding product just right for the job.
A
TOP VIEW
Laird Technologies’ Slot Mount Series of beryllium copper shielding gaskets is designed for use
in a wide variety of slotted applications. This economical product line is ideal for both grounding
and shielding applications.
E
D Pitch
Approx. Length
Slot
FEATURES
*P
Material
Thickness
• Minimal slot fabrication cost
• Easy and cost-effective installation since
fasteners and adhesives are not required
• Bi-directional wiping and compression action
to accommodate a wide variety of designs
• The Slot Mount Series is available in your
B
choice of finishes
RIGHT VIEW
• Ideal for grounding and shielding in the
See page 2-2
Recommended Mounting Hole Pattern
following electronic enclosure applications:
for dimensions.
– Front panel handles – Chassis covers
– Plug-in units – Backplanes
– Subrack assemblies
• Standard (77-Series) and UltraSoft
®
(78-Series
low compression versions) are also supplied
in 25.0 ft. (7.6 m) coils
H
global
solutions:
local
support
USA: +1.866.928.8181
Europe: +49.0.8031.2460.0
Asia: +86.755.2714.1166
TM
M
C
See page 2-2
for dimensions.
Q Radius (R)
www.lairdtech.com
Slot Mount Series are available with Universal and Tape Track mounting
options, see page 1-9, 1-10.
Slot Mount Series
Innovative
Technology
for a
Connected
World
FINGERSTOCK DIMENSIONS
SERIES
77-010
77-011
77-015
77-016
77-017
77-018
77-019
77-020
77-021
77-023
77-024
77-025
77-026
77-027
77-028
77-029
77-030
77-031
77-032
77-035
77-036
77-037
77-038
77-039
77-040
77-041
77-042
77-044
A
B
C
D
E
H
M
*N
*O
*P
RECOMMENDED
Q
(R)
LENGTH # OF
APPROX FING
86
—
57
—
1
—
1
—
2
—
3
—
4
—
2
—
86
—
1
—
2
—
3
—
4
—
5
—
6
—
1
—
2
—
3
—
4
—
2
—
4
—
6
—
8
—
1
—
2
—
3
—
4
—
6
—
SERIES
77-045
77-046
77-047
77-048
77-050
77-051
77-052
77-053
77-054
77-055
77-058
77-059
77-062
77-063
77-064
77-065
77-070
77-076
77-087
77-088
77-089
77-094
77-096
77-097
77-099
77-100
77-101
A
B
C
D
N/A
—
E
N/A
—
H
M
*N
*O
*P
RECOMMENDED
Q
(R)
LENGTH # OF
APPROX FING
0.169
0.356
0.543
0.730
0.917
1.104
1.291
1.478
1.665
1.852
0.917
1
—
2
—
3
—
4
—
5
—
6
—
7
—
8
—
9
—
10
—
5
—
64
—
1
—
2
—
3
—
4
—
86
—
1
—
7
—
8
—
3
—
2
—
4
—
43
—
5
—
6
—
7
—
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020 16.000
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (406.400)
0.600 0.220 0.005 0.282 0.032 0.140 0.180 0.140 0.520 0.070 0.040 16.000
(15.240) (5.588) (0.127) (7.163) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (406.400)
0.600 0.220 0.005
(15.240) (5.588) (0.127)
0.320 0.110 0.004
(8.128) (2.794) (0.102)
N/A
—
N/A
—
N/A
—
N/A
—
0.140 0.180 0.140 0.520 0.070 0.040
0.085 0.110 0.090 0.260 0.040 0.020
0.250
0.169
0.356
0.543
0.730
0.532
(3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (6.350)
(2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (4.293)
0.320 0.110 0.004
(8.128) (2.794) (0.102)
0.085 0.110 0.090 0.260 0.060 0.040
Fingerstock Gaskets
(2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (4.293)
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.040
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (9.042)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6604) (1.524) (1.016) (13.792)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (18.542)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (23.292)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (28.042)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (32.791)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (37.541)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (42.291)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (1.016) (47.041)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (23.292)
0.370 0.130 0.004 0.250 0.025 0.085 0.110 0.090 0.310 0.040 0.020 16.000
(9.398) (3.302) (0.102) (6.350) (0.635) (2.159) (2.794) (2.286) (7.874) (1.016) (0.508) (406.400)
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.048 0.025
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.048 0.025
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.048 0.025
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.048 0.025
0.169
0.356
0.543
0.730
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.219) (0.635) (4.293)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.219) (0.635) (9.042)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.219) (0.635) (13.792)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.219) (0.635) (18.542)
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.062 0.035 16.000
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.575) (0.889) (406.400)
0.600 0.220 0.005
(15.240) (5.588) (0.127)
N/A
—
N/A
—
0.140 0.180 0.140 0.520 0.070 0.020
0.340
1.291
1.478
0.810
0.389
1.096
(3.556) (4.572) (3.556) (13.208) (1.778) (0.508) (8.636)
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
0.600 0.220 0.005 0.282 0.032 0.140 0.180 0.140 0.520 0.070 0.040
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (9.042)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (13.792)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (18.542)
(15.240) (5.588) (0.127) (7.163) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (13.513)
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.060 0.035 16.000
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.524) (0.889) (406.400)
0.370 0.130 0.004
(9.398) (3.302) (0.102)
N/A
—
N/A
—
0.085 0.110 0.090 0.300 0.040 0.020
0.225
0.475
0.725
0.975
1.225
1.475
0.343
0.718
1.093
1.468
0.480
0.980
1.480
1.980
0.169
0.356
0.543
0.730
1.104
(2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (5.715)
0.370 0.130 0.004 0.250 0.025 0.085 0.110 0.090 0.300 0.040 0.020
0.370 0.130 0.004 0.250 0.025 0.085 0.110 0.090 0.300 0.040 0.020
0.370 0.130 0.005 0.250 0.025 0.085 0.110 0.090 0.300 0.040 0.020
0.370 0.130 0.005 0.250 0.025 0.085 0.110 0.090 0.300 0.040 0.020
0.370 0.130 0.005 0.250 0.025 0.085 0.110 0.090 0.300 0.040 0.020
0.800 0.320 0.004
(20.320) (8.128) (0.102)
N/A
—
N/A
—
0.200 0.180 0.220 0.720 0.070 0.040
(9.398) (3.302) (0.102) (6.350) (0.635) (2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (12.065)
(9.398) (3.302) (0.102) (6.350) (0.635) (2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (18.415)
(9.398) (3.302) (0.127) (6.350) (0.635) (2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (24.765)
(9.398) (3.302) (0.127) (6.350) (0.635) (2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (31.115)
(9.398) (3.302) (0.127) (6.350) (0.635) (2.159) (2.794) (2.286) (7.620) (1.016) (0.508) (37.465)
(5.080) (4.572) (5.588) (18.288) (1.778) (1.016) (8.712)
0.800 0.320 0.004 0.375 0.032 0.200 0.180 0.220 0.720 0.070 0.040
0.800 0.320 0.005 0.375 0.032 0.200 0.180 0.220 0.720 0.070 0.040
0.800 0.320 0.005 0.375 0.032 0.200 0.180 0.220 0.720 0.070 0.040
0.310 0.120 0.003 0.250 0.020 0.090 0.115 0.095 0.250 0.040 0.015
0.310 0.120 0.003 0.250 0.020 0.090 0.115 0.095 0.250 0.040 0.015
0.310 0.120 0.003 0.250 0.020 0.090 0.115 0.095 0.250 0.040 0.015
0.310 0.120 0.003 0.250 0.020 0.090 0.115 0.095 0.250 0.040 0.015
0.280 0.110 0.002
(7.112) (2.794) (0.051)
N/A
—
N/A
—
0.075 0.110 0.090 0.220 0.040 0.030
(20.320) (8.128) (0.102) (9.525) (0.813) (5.080) (4.572) (5.588) (18.288) (1.778) (1.016) (18.237)
(20.320) (8.128) (0.127) (9.525) (0.813) (5.080) (4.572) (5.588) (18.288) (1.778) (1.016) (27.762)
(20.320) (8.128) (0.127) (9.525) (0.813) (5.080) (4.572) (5.588) (18.288) (1.778) (1.016) (37.287)
(7.874) (3.048) (0.076) (6.350) (0.508) (2.286) (2.921) (2.413) (6.350) (1.016) (0.381) (12.192)
(7.874) (3.048) (0.076) (6.350) (0.508) (2.286) (2.921) (2.413) (6.350) (1.016) (0.381) (24.892)
(7.874) (3.048) (0.076) (6.350) (0.508) (2.286) (2.921) (2.413) (6.350) (1.016) (0.381) (37.592)
(7.874) (3.048) (0.076) (6.350) (0.508) (2.286) (2.921) (2.413) (6.350) (1.016) (0.381) (50.292)
(1.905) (2.794) (2.286) (5.588) (1.016) (0.762) (4.293)
0.563 0.110 0.003 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
0.563 0.110 0.003 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
0.600 0.220 0.005 0.282 0.032 0.140 0.180 0.140 0.520 0.070 0.040
0.358 0.128 0.003 0.202 0.018 0.110 0.100 0.115 0.300 0.030 0.030
0.600 0.220 0.005 0.282 0.032 0.140 0.180 0.095 0.520 0.040 0.040
(14.300) (2.794) (0.076) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (32.791)
(14.300) (2.794) (0.076) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (37.541)
(15.240) (5.588) (0.127) (7.163) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (20.574)
(9.093) (3.251) (0.076) (5.131) (0.457) (2.794) (2.54) (2.921) (7.620) (0.762) (0.762) (9.881)
(15.240) (5.588) (0.127) (7.163) (0.813) (3.556) (4.572) (2.413) (13.208) (1.016) (1.016) (27.838)
0.600 0.220 0.005 0.375 0.032 0.140 0.180 0.140 0.520 0.070 0.040 16.000
(15.240) (5.588) (0.127) (9.525) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (406.400)
0.600 0.220 0.005 0.375 0.032 0.140 0.180 0.140 0.520 0.070 0.040
0.600 0.220 0.005 0.375 0.032 0.140 0.180 0.140 0.520 0.070 0.040
0.600 0.220 0.005 0.375 0.032 0.140 0.180 0.140 0.520 0.070 0.040
1.378
1.660
1.942
(15.240) (5.588) (0.127) (9.525) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (35.001)
(15.240) (5.588) (0.127) (9.525) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (42.164)
(15.240) (5.588) (0.127) (9.525) (0.813) (3.556) (4.572) (3.556) (13.208) (1.778) (1.016) (49.327)
0.280 0.110 0.002 0.187 0.018 0.075 0.110 0.090 0.220 0.040 0.030
0.280 0.110 0.002 0.187 0.018 0.075 0.110 0.090 0.220 0.040 0.030
0.280 0.110 0.002 0.187 0.018 0.075 0.110 0.090 0.220 0.040 0.030
0.320 0.110 0.004 0.187 0.018 0.085 0.110 0.090 0.260 0.040 0.020
(7.112) (2.794) (0.051) (4.750) (0.457) (1.905) (2.794) (2.286) (5.588) (1.016) (0.762) (9.042)
(7.112) (2.794) (0.051) (4.750) (0.457) (1.905) (2.794) (2.286) (5.588) (1.016) (0.762) (13.792)
(7.112) (2.794) (0.051) (4.750) (0.457) (1.905) (2.794) (2.286) (5.588) (1.016) (0.762) (18.542)
(8.128) (2.794) (0.102) (4.750) (0.457) (2.159) (2.794) (2.286) (6.604) (1.016) (0.508) (28.042)
* May vary depending upon application.
EMI-DS-FINGERSTOCK-SLOT MOUNT 1112
Any information furnished by Laird Technologies, Inc. and its agents is believed to be accurate and reliable. All specifications are subject to change without notice. Responsibility for the use and application of Laird Technologies materials rests with the end user. Laird Technologies makes no warran-
ties as to the fitness, merchantability, suitability or non-infringement of any Laird Technologies materials or products for any specific or general uses. Laird Technologies shall not be liable for incidental or consequential damages of any kind. All Laird Technologies products are sold pursuant to the
Laird Technologies’ Terms and Conditions of sale in effect from time to time, a copy of which will be furnished upon request. © Copyright 2011 Laird Technologies, Inc. All Rights Reserved. Laird, Laird Technologies, the Laird Technologies Logo, and other marks are trade marks or registered trade
marks of Laird Technologies, Inc. or an affiliate company thereof. Other product or service names may be the property of third parties. Nothing herein provides a license under any Laird Technologies or any third party intellectual property rights.
Embedded System
京公网安备 11010802033920号
EEWORLD
