Thyristors
Surface Mount – 200V-600W > 2N6071A/B Series
Maximum Ratings and Thermal Characteristics
(T
J
= 25°C unless otherwise noted)
Rating
Symbol
Value
Unit
*Peak Repetitive Off-State Voltage (Note 1)
(T
J
= -40 to 110°C, Sine Wave, 50 to 60 Hz, Gate Open)
2N6071A,B
2N6073A,B
2N6075A,B
*On-State RMS Current (T
C
= 85°C) Full Cycle Sine Wave 50 to 60 Hz
*Peak Non-repetitive Surge Current (One Full cycle, 60 Hz, T
J
= +110°C)
Circuit Fusing Considerations (t = 8.3 ms)
*Peak Gate Power (Pulse Width “1.0 µs, T
C
= 85°C)
*Average Gate Power (t = 8.3 ms, T
C
= 85°C)
*Peak Gate Voltage (Pulse Width “1.0 µs, T
C
= 85°C)
*Operating Junction Temperature Range
*Storage Temperature Range
Mounting Torque (6-32 Screw) (Note 2)
V
DRM
,
V
RRM
200
400
600
I
T(RMS)
I
TSM
I
2t
P
GM
P
G(AV)
V
GM
T
J
T
stg
_
4.0
30
3.7
10
0.5
5.0
-40 to +110
-40 to +150
8.0
A
A
A2s
W
W
V
°C
°C
in. lb.
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied.
Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
1. V
DRM
and V
RRM
for all types can be applied on a continuous basis. Blocking voltages shall not be tested with a constant current source such that the voltage ratings of the devices are exceeded.
2. Torque rating applies with use of a compression washer. Mounting torque in excess of 6 in. lb. does not appreciably lower case-to-sink thermal resistance. Main terminal 2 and heatsink
contact pad are common.
Thermal Characteristics
Rating
*Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Ambient (Note 1)
Maximum Lead Temperature for Soldering Purposes, 1/8” from case for
