201080F • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • August 3, 2017
1
DATA SHEET • SKY13323-378LF SPDT SWITCH
Table 1. SKY13323-378LF Signal Descriptions
Pin
1
2
3
Name
OUTPUT1
GND
OUTPUT2
Description
RF port. Must be DC blocked.
Ground
RF port. Must be DC blocked.
Pin
4
5
6
VCTL2
INPUT
VCTL1
Name
Description
DC control voltage
RF port. Must be DC blocked
DC control voltage
Table 2. SKY13323-378LF Absolute Maximum Ratings
1
Parameter
Input power
>500 MHz, 5 V
>500 MHz, 3 V
Storage temperature
Operating temperature
P
IN
+32
+31
T
STG
T
OP
–65
–40
+150
+85
dBm
dBm
C
C
Symbol
Minimum
Typical
Maximum
Units
1 Exposure to maximum rating conditions for extended periods may reduce device reliability. There is no damage to device with only one parameter set at the limit and all other parameters
set at or below their nominal value. Exceeding any of the limits listed here may result in permanent damage to the device.
ESD HANDLING:
Although this device is designed to be as robust as possible, electrostatic discharge (ESD) can damage this device.
This device must be protected at all times from ESD when handling or transporting. Static charges may easily produce
potentials of several kilovolts on the human body or equipment, which can discharge without detection.
Industry-standard ESD handling precautions should be used at all times.
August 3, 2017 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 201080F
201080-007
0.5
DATA SHEET • SKY13323-378LF SPDT SWITCH
Table 5. SKY13323-378LF Truth Table
1
VCTL1 (Pin 6)
0
1
VCTL2 (Pin 4)
1
0
INPUT to OUTPUT1 Path
Isolation
Insertion loss
INPUT to OUTPUT2 Path
Insertion loss
Isolation
1 “1” = +1.8 V to +5 V. “0” = 0 V to +0.2 V. Any state other than described in this Table places the switch into an undefined state. An undefined state will not damage the device.
Evaluation Board Description
The SKY13323-378LF Evaluation Board is used to test the
performance of the SKY13323-378LF SPDT Switch. An Evaluation
Board schematic diagram is provided in Figure 8. An assembly
drawing for the Evaluation Board is shown in Figure 9.
Package and Handling Information
Instructions on the shipping container label regarding exposure to
moisture after the container seal is broken must be followed.
Otherwise, problems related to moisture absorption may occur
when the part is subjected to high temperature during solder
assembly.
The SKY13323-378LF is rated to Moisture Sensitivity Level 1
(MSL1) at 260
C.
It can be used for lead or lead-free soldering.
Care must be taken when attaching this product, whether it is
done manually or in a production solder reflow environment.
Production quantities of this product are shipped in a standard
tape and reel format. For packaging details, refer to the Skyworks
Application Note,
Discrete Devices and IC Switch/Attenuators
Tape and Reel Package Orientation,
document number 200083.
Package Dimensions
The PCB layout footprint for the SKY13323-378LF is provided in
Figure 10. Typical part markings are shown in Figure 11. Package
dimensions are shown in Figure 12, and tape and reel dimensions
are provided in Figure 13.
C1
OUTPUT1
C4
VCTL1
INPUT
C3
OUTPUT2
C6
C1, C3, and C5 are DC blocking capacitors (100 pF)
