ADAM-4118
ADAM-4150
ADAM-4168
Robust 8-ch Thermocouple Input Module
with Modbus
Robust 15-ch Digital I/O Module with
Modbus
Robust 8-ch Relay Output Module with
Modbus
ADAM-4118
RoHS
2002/95/EC
COMPLIANT
ADAM-4150
RoHS
2002/95/EC
COMPLIANT
ADAM-4168
RoHS
2002/95/EC
COMPLIANT
Specifications
General
Power Consumption
0.5W @ 24 V
DC
Specifications
General
Power Consumption
0.7 W @ 24 V
DC
Specifications
General
Power Consumption
1.8 W @ 24 V
DC
Analog Input
Channels
Input Impedance
Input Type
Input Range
Thermocouple
J
K
T
E
0 ~ 760°C
0 ~ 1,370°C
-100 ~ 400°C
0 ~ 1,000°C
8 differential and
independent configuration
channels
Voltage: 20 MΩ
Current: 120
Ω
T/C, mV, V, mA
Digital Input
Channels
Input Level
Dry contact:
7
Relay Output
Output Channels
Contact Rating
(Resistive)
8 Form A
0.5 A @ 120 V
AC
0.25 A @ 240 V
AC
1 A @ 30 V
DC
0.3 A @ 110 V
DC
750 V
AC
(50/60 Hz)
1 G
Ω
min. @ 500 V
DC
R
S
B
500 ~ 1,750°C
500 ~ 1,750°C
500 ~ 1,800°C
Logic level 0: Close to GND
Logic level 1: Open
Wet contact:
Logic level 0: 3 V max
Logic level 1: 10 ~ 30 V
(Note: The Digital Input Level 0 and 1 status can be
inverted)
Supports 3 kHz Counter Input (32-bit + 1-bit
overflow)
Supports 3 kHz Frequency Input
Supports Invert DI Status
Over Voltage Protection
40 V
DC
±15 mV, ±50 mV,
±100 mV, ±500 mV,
±1 V, ±2.5 V
Current mode
±20 mA, 4 ~ 20 mA
Accuracy
Voltage mode: ±0.1% or
better
Current mode: ±0.2% or
better
Resolution
16-bit
Sampling Rate
10/100 samples/sec
(selected by Utility)
CMR @ 50/60 Hz
92 dB
NMR @ 50/60 Hz
60 dB
Overvoltage Protection
±60 V
DC
High Common Mode
200 V
DC
Span Drift
±25 ppm/°C (Typical)
Zero Drift
±6μV/°C
Built-in TVS/ESD Protection
Burn-out Detection
Voltage mode
Digital Output
Channels
8, open collector to 40 V
(0.8A max. load)
Power Dissipation
1W load max
RON Maximum
150 mΩ
Supports 1 kHz Pulse Output
Supports High-to-Low Delay Output
Supports Low-to-High Delay Output
Breakdown Voltage
Initial Insulation
Resistance
Relay Response
On: 3ms
Time (Typical)
Off: 1ms
Total Switching Time
10 ms
Supports 100 Hz pulse output
Maximum Operating
50 operations/min
Speed
(at related load)
Common Specifications
General
Power Input
Watchdog Timer
Connector
Isolation Voltage
Unregulated 10 ~ 48 V
DC
System (1.6 second) &
Communication
2 x plug-in terminal
blocks (#14 ~ 22 AWG)
3,000 V
DC
Supported Protocols
ASCII Command and
Modbus/RTU
Ordering Information
ADAM-4118
ADAM-4150
ADAM-4168
Environment
Operating Humidity
5 ~ 95% RH
Operating Temperature
-40 ~ 85°C
(-40 ~ 185°F)
Storage Temperature
-40 ~ 85°C
(-40 ~ 185°F)
Robust 8-ch
Thermocouple Input
Module w/ Modbus
Robust 15-ch Digital I/O
Module with Modbus
Robust 8-ch Relay
Output Module with
Modbus
Online Download
www.advantech.com/products
All product specifications are subject to change without notice
Last updated : 27-Jul-2016
