03S_10XC62K 02.9.12 3:08 PM ページ 359
Series
Series
Negative Voltage Regulators
Negative Voltage Regulators
NCMOS
Low Power Consumption
NSmall
Input-Output Voltage Differential
: 0.12V @ 50mA,
0.38V @ 100mA
NMaximum
Output Current : 100mA (V
OUT
=-5.0V)
NHighly
Accurate
NOutput
Voltage Range
NSupply
Current
: ±2% (±1%)
: -2.1V~ -6.0V
: 3.0µA (V
OUT
=-5.0V)
■Applications
GBattery
Powered Equipment
GPortable
& Cellular Phones
GVarious
Portable Equipment
GPower
Supply for GaAs Applications
3
NSOT-23/SOT-89/TO-92
Package
■General Description
The XC62K series are highly precise, low power consumption, negative
voltage regulators, manufactured using CMOS and laser trimming
technologies. The series achieves high output currents with small input-
output voltage differentials, and consists of a high precision voltage
reference, an error correction circuit, and an output driver with current
limitation.
SOT-23 (150mW), SOT-89 (500mW) and TO-92 (300mW) packages are
available.
■Features
Ultra Small Input-Output Voltage Differential
: 50mA output possible with a 0.12V
differential (V
OUT
=-5.0V).
Maximum Output Current
: 100mA (within max. power
dissipation, V
OUT
= -5.0V)
Output Voltage Range
: -2.1V ~ -6.0V in 0.1V increments.
-5.0, -4.0, -3.0V, -2.5V standard.
(All other voltages are semi-custom)
Highly Accurate
: Output voltage ±2%
(±1% for semi-custom products)
Low Power Consumption
: Typ. 3.0µA @ V
OUT
= -5.0V
Output Voltage Temperature Characteristics
: Typ. ±100ppm/°C
Input Stability
: Typ. 0.1%/V
Ultra Small Packages
: SOT- 23 (150mW) mini-mold,
SOT-89 (500mW) mini-power mold
TO-92 (300mW)
■Typical Application Circuit
■Typical Performance
Characteristic
XC62KN3002
（-3.0V）
5
+
1µF
（Tantalum）
V
SS
C
L
+
1µF
（Tantalum）
OUT
Supply Current:Iss
µA）
（
C
IN
4
Topr＝25℃
3
2
−30℃
1
0
0
−2
−4
−6
−8
−10
80℃
IN
-V
IN
-V
OUT
Input Voltage:V
IN
（V）
359
03S_10XC62K 02.9.12 3:08 PM ページ 362
XC62K
GTO-92
4.65
+0.35
-0.45
Series
3.7±0.3
3
0.45±0.1
10.0min
0.4±0.05
2.5
-0.1
+0.4
2.5
-0.1
+0.4
■Marking
GSOT-23,
SOT-89
q
lntegral Number of Output Voltage
DESIGNATOR VOLTAGE(V) DESIGNATOR VOLTAGE(V)
2
2.w
3.w
4.w
5
6
5.w
6.w
1 2 3 4
2
1
4
3
1.6±0.1
4.8
-0.5
+0.4
3
4
SOT-23
（TOP VIEW）
SOT-89
（TOP VIEW）
w
Decimal number of Output Voltage
DESIGNATOR VOLTAGE(V) DESIGNATOR VOLTAGE(V)
A
B
C
D
E
q.0
q.1
q.2
q.3
q.4
F
H
K
L
M
q.5
q.6
q.7
q.8
q.9
e
Polarity of Output Voltage
DESIGNATOR
5
POLARITY
Negative
r
Assembly Lot Number
Based on internal standards.
362
03S_10XC62K 02.9.12 3:08 PM ページ 363
XC62K
Series
GTO-92
q
Represents the Polarity of Output Voltage
DESIGNATOR
62K
1
2 3 4 5
6 7
we
Represents the Detect Voltage
DESIGNATOR
OUTPUT CONFIGURATION
—
N
w
3
e
3
0
VOLTAGE（V）
3.3
5.0
r
Represents the temperature Characteristics
DESIGNATOR TEMPERATURE CHARACTERISTICS
0
TPY±100ppm
5
t
Represents the Detect Voltage Accuracy
DESIGNATOR
1
2
TO-92（T Type）
(TOP VIEW)
DETECT VOLTAGE ACCURACY
within ±1％（semi-custom）
within ±2％
y
Represents a least significant digit of the
produced year
DESIGNATOR
0
1
PRODUCED YEAR
2000
2001
3
u
Denotes the production lot number
0 to 9, A to Z repeated(G.I.J.O.Q.W excepted)
■Block Diagram
V
SS
（GND）
■Absolute Maximum Ratings
PARAMETER
Input Voltage
SYMBOL
V
IN
I
OUT
V
OUT
RATINGS
–12
200
–V
DD
–0.3 ~ V
IN
+0.3
150
P
d
500
300
T
opr
T
stg
–30 ~ +80
–40 ~ +125
Ta=25°C
UNITS
V
mA
V
Vref
Current
Limit
+
Output Current
Output Voltage
-
SOT-23
−V
IN
−V
OUT
Continuous
Total Power
Dissipation
SOT-89
TO-92
mW
Operating Ambient
Temperature
Storage Temperature
°C
°C
Note: Please ensure that I
OUT
is less than Pd
÷
(V
OUT
- V
IN
)
363
